computer transverse slicer machine/film paper cutting machine

Specifications

This machine is suitable for transverse slicing of such roll material as wet glue tape/film/PVC and aluminium foil.etc.



computer transverse slicer machine/film paper cutting machine







This machine is suitable for transverse slicing of such roll materials as wet glue tape, paper, film, PVC and aluminium foil, etc.
Performance and Characteristics:
1. Computer control, setting of fixed length.
2. Automatic counting, Acousto-optic alarm.
3. Photoelectric tracking control, accurate slicing length, automatically stopping the machine when the label is lost.
4. The roll-releasing mechanism can be equipped with automatic deviation-rectifying and magnetic powder tension control device.

Model	QZ-600	QZ-800	QZ-1000
Max.Cutting Width	600 mm	800 mm	1000 mm
Max.Cutting Length	999 mm	999 mm	999 mm
Max.Cutting Speed	40m/min	30m/min	30m/min
Total Power	2.1KW	2.8KW	3.6KW
Weight of Machine	700kg	800 kg	1000 kg
Overall Dimension	3000x1100x1200mm	3000x1300x1200mm	3000x1500x1200mm
