Help CenterDT-A3C Full Automatic Card Punching Machine
Related Products
Specifications
1.Stable performance2.Smart digital control
3.Productivity 1200 cards/hour
DT-A3C Full Automatic Card Punching Machine
DT-A3C Full Automatic Card Punching Machine, put some hundreds sheet on machine, automatic load the sheet into punching table by air tool, sensors automatic read the printing mark, automatic feed sheet for punching and collect the punched cards.
High sensitivity optical fiber sensor cooperating imported no-crevice built-in roller screw mandrel to feed material, the position parameter of the punching spot can be adjusted, with high precision.
·Use the hydraulic punching head to be the punching motivity, with low noise and stable motivity, the pressure and
punching speed can be adjusted as needed, when the punched cards with different thickness will have better effect.
·Advanced card collecting system can send off the cards from different mould and collect the cards independently, there is no need to detach the punched cards, the cards are collected independently not to affect the punching speed, the machine can punch the cards quickly and reliably.(especially available for the material punched to tiers)
·Controlled by PLC and running automatically, the machine will alarm and halt in case of errors.
High sensitivity optical fiber sensor cooperating imported no-crevice built-in roller screw mandrel to feed material, the position parameter of the punching spot can be adjusted, with high precision.
·Use the hydraulic punching head to be the punching motivity, with low noise and stable motivity, the pressure and
punching speed can be adjusted as needed, when the punched cards with different thickness will have better effect.
·Advanced card collecting system can send off the cards from different mould and collect the cards independently, there is no need to detach the punched cards, the cards are collected independently not to affect the punching speed, the machine can punch the cards quickly and reliably.(especially available for the material punched to tiers)
·Controlled by PLC and running automatically, the machine will alarm and halt in case of errors.
Technican parameter:
| Punching Materials | PVC, ABS, PET, PETG, Paper, mixed plastic materials...... |
| Punching Sheet | 3*7, 3*8, 3*9, 4*8, 4*9, 5*5 or other format |
| Voltage Input | 380V 50/60Hz |
| Power | 3.5KW |
| Air Supply | 0.6MPa 6KG/cm2 no water |
| Punching Thickness | 0.1mm-1.2mm |
| Punching Efficiency | 8000-20000pcs card per hour |
| Control Method | PLC , Touch Screen, Servo Motor System |
| Punchng Precision | 0.10mm |
| Operator | 1 person |
| Dimension | 1800mm*830mm*1520mm |
| Net/Gross Weight | 1000KGS/1080KGS |
