Specifications
PVC Card Laminatorto laminate credit card, plastic card, exibition show card ect
water cooling
PLC control
DT credit Card Laminator Machine
RG-C-5S(PLC Touch Screen)PVC card laminating professional machine is the high efficiency equipment was made for professional manufacturer of IC,ID inlay. It is low wastage rate, easy to operate effectively. As the professional PVC laminator machine it also can satisfy the PVC card company and PVC card factory enough to produce the second generation identification cards and good quality certificate cards,banking cards,one card solution for bus ,high way,social insurance card and so on.
DT credit Card Laminator Machine
Model |
RG-C-5L |
Control System |
Microcomputer + Inside Oil Hydraulic Pressure System |
Voltage |
380V 50/60Hz |
Power |
7KW |
Pressure System |
Low Pressure System |
Max. Pressure |
32Tons |
Pressure step |
3 steps |
Temperature Range |
O-300°C |
Working Temperature |
80-140°C |
Time Range |
0-999 Seconds |
Cycle time |
6-12minutes by different materials |
Opening Height |
45mm |
Lamination Size |
A4 |
Work Efficiency |
1800-3500pcs cards per hour |
Lamination Opening |
3 openings for heating 3 opening for cooling |
Lamination Layers |
1-72layers |
Cooling System |
Automatic water and air cooling |
Packing Size |
860mm*580mm*1700mm |
Weight |
415KG |
Power Consumption |
1.5 kwh electricity each hour |
Operate Person |
1 |
