factory price of melting industrial furnace from china

Specifications

melting industrial furnace
Chamber size customizable
30 section program, PID control,SCR.
Direct and technical manufacture

KJ-1200X melting industrial  furnace











Model: KJ-1200X    melting industrial  furnace

Parameter of chamber size: customizable







Main specification

Furnace Construction	Heavy duty double layer structure with cooling fan. Lower teperature in outside case High purity ceramic fiber insulation (energy saving 40% and weight lighter about 30% than old furnace) PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier) The door can be designed to up and down type or slid type
Heating rate	0~15°C/min (suggestion: ≤10°C)
Thermocouple	K-type
Heating Element	Fe-Cr-Al Alloy doped by Mo/Ni-Cr-Al wire
Working Temperature	1000 ℃ for continuously (1200 ℃ <2 hours)
Temperature Controller	30 segments programmable PID digital auto temp control  via SCR(Silicon Controlled Rectifier)
Temperature Uniformity	+/- 5℃ in heating zone
Control Accuracy	+/- 1 ℃
Packing	plastic paper inside, polyfoam filled, wooden box outside.
Power	2~6 KW
Voltage	208~240V single phase  50/60 Hz
Warranty	One year limited with life time suppport(consumable parts  are not covered by the warranty.)
Box size	500 x 485 x 700mm  (with package 600 x 585 x 900mm)
Weight	net weight 95Kg/gross weight120 Kg
Chamber	150x150x150mm (6"x6"x6") 150x150x200mm (6"x6"x8") 200x200x200mm (8"x8"x8") 200x200x300mm (8"x8"x12") 250x250x300mm (10"x10"x12") 300x300x400mm (12"x12"x16") 350x350x400mm (14"x14"x16") 400x400x400mm (16"x16"x16") 500x500x500mm (20"x20"x20") Note: chamber sizes are customizable

 Special requirement can be designed according to your requirement





Details of applications

Stress Relieving

Ashing Crystallize

Melting or smelting

Heat treating or Preheating;

Quench or Hardening or Austemper

Annealing or Tempering or Normalizing

Sintering or Roasting or Forging or calcining;

Gravimetric Quantitative Temperature analysis

Synthesis and degradation or pyrolysis or decomposing





 Photos of   melting industrial  furnace









KeJia Furnace Co.,Ltd

Zhengzhou KeJia Furnace Co.,Ltd
We have our own manufacturing base factory as while as many sub-contracting factories, which enable us a reliable manufacturing ability and quality control system.

Our team has rich experience in the fields of thermal processing, high temperature furnace/kiln,laboratory equipment as well as other related fields. We are capable of supplying both the equipment and technologies according to customers' different requirements and realities, and we have lots of successful projects in many different countries and regions, like East Europe, South Asia, South America, Australia and New Zealand, and Africa. "Profession, Quick Response, Hard Work, and Sincerity" is the strength of our team, earning us a sound reputation among our clients.

We are open and willing to work with clients from different countries and regions. We will make the cooperation and share the mutual benefits together!

















Warranty

melting industrial furnace   is warranted to be free from defects in materials or workmanship for 1 years from the date of purchase. Within this period, across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs. Replacement will be shipped to you after photo or other evidence are provided and investigated.





Deliver by air, by express, by sea or shipping timely according to your requirement.

Pls tell us the shiping method you prefer and the destination airport or seaport in advance.

Then we can check the freight for you.



Our service

Deliver products timely

Reply your inquiry at my first convenience

Any problems please contact me, I’ll go through all the questions with you.

We will offer the tracking No. for checking the status we ship the doods.
