high temperature mosi2 heating element rtp tube furnace for sale
KJ-series rtp tube furnace use high pure alumina or quartz tube as furnace ing range is from 800°C to 1600°C.KJ series tube furnace are widely used in the labs of university and research institutions,also used in factory for production.
The precision temperature controller will provide 30 segments heating and cooling steps with +/- 1 °C accuracy. This furnace system also includes an anti-corrosive Pirani Capacitance Diaphragm Gauge to enable vacuum measurements with aggressive gases.
Features of rtp tube furnace :
1.Energy saving
2.A wide range of pressure from standard atmosphere to low pressure 10 Pa
3.Quick and professional technical support
4.Uniform temperature field
5.Excellent temperature uniformity
Application of rtp tube furnace :
Laboratory rotary tube furnace is widely used for various CVD experimental reaction temperature at 1100 ℃, it can also be used for vacuum sintering,vacuum protective atmosphere sintering nanomaterials preparation,battery materials preparation and other research field.
Technical Parameter for rtp tube furnace :
Mode |
KJ-1200 |
KJ-1400 |
KJ-1600 |
Max.temperature |
1200°C |
1400°C |
1600°C |
Working temperature |
1100°C |
1300°C |
1500°C |
Heating rate |
0-20°C/min |
0-10°C/min |
0-10°C/min |
Accuracy |
+-1°C |
+-1°C |
+-1°C |
Temperature uniform |
+-5°C |
+-5°C |
+-5°C |
Heating elements |
Fe-Cr-Al-Mo wire |
SIC heating element |
MoSi2 heating element |
thermocouple |
K |
S |
B |
Furnace tube |
Quartz tube |
Alumina tube |
Alumina tube |
Power |
110-415V 50/60Hz |
110-415V 50/60Hz |
110-415V 50/60Hz |
Warranty |
One year |
One year |
One year |
Standard chamber size |
Delivery time |
Standard chamber size |
Delivery time |
Dia40*300mm |
2 days |
Dia40*450mm |
2 days |
Dia60*300mm |
2 days |
Dia60*450mm |
2 days |
Dia80*300mm |
2 days |
Dia80*450mm |
2 days |
Dia100*300mm |
30 days |
Dia100*450mm |
30 days |
Dia120*300mm |
30 days |
Dia120*450mm |
30 days |
Note: there are different chamber sizes for your choice.
Detail Pictures:
Packing: Plastic paper inside, Polyfoam filled, Wooden box outside
Payment: T/T, West union, etc
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Professional factory : We are manufacturer, specializing in laboratory furnaces.
Welcome your inquiry and trail order!
