Specifications
KJ-1400C Box lifting high temprature furnace forno a muffolast lower,super performance
2.heated by SiC element
Bottom loading furnace box forno a muffola
Model: KJ-1400 Box lifting high temprature furnace
Size: 200x200x200mm (8"x8"x8"), (WxHxD).
Bottom loading furnace
Features
1. Operation Temperature: 1300°C (1400°C for short time).
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 50 segments programmable.
Bottom loading furnace
Descriptions
Chamber Size |
200x200x200 mm (8"x8"x8") |
Working Temperature |
1300°C (continuous) |
Maximum Temperature |
1400°C |
Temperature Control |
50 steps programmable and PID automatic control |
Heating Rate |
0~15°C/min (suggestion: ≤10°C) |
Temperature Accuracy |
+/-1°C |
Heating Element |
Molybdenum Disilicide (MoSi2) |
Working Voltage |
AC 220V, Single Phase, 60/50 Hz (or according to your requirement) |
Max. Power |
4 KW |
Outside Size |
500 x 485 x 700 mm |
Net Weight |
150 Kg |
Note: there are different chamber sizes for your choice.
Bottom loading furnace
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: T/T, West union, etc.
Shipping and Delivery: by air/sea, in 15 days after receiving the payment
Warranty: 1 year limited warranty on all electronic parts.
Welcome to pay close attation to our other furnace: Tube furnaces, (Vacuum) Crucible furnaces, Vacuum Box furnace, Double(Multi) zones Tube furnaces, Multi-position Rotary Tube furnace, Bottom Loading furnace, MoSi2 heating elements, SiC heating elements, etc.
