Specifications
Elevate Furnace for Laboratory up to 1700CMorgan materials fibers furnace
PID control
High quality heating elements
Elevator electric large muffle furnace up to 1700 C
Characteristics of elevator electric furnace
Open type: open side, with a lock, the door can be rotated
1, the control precision is ± 1 °C: uniformity: ± 1 °C (according to the heating chamber size).
2, convenient operation, programmable, PID auto tuning, automatic heating, automatic heat insulation, automatic cooling, no duty; can reprovision communication with the computer through the computer operation furnace, electric furnace, electric furnace (start stop pause, set the heating curve, heating temperature curve, history curve of storage
3, fast temperature (1 °C /h and 40 °C /min adjustable heating rate).
4, energy saving (furnace production and import fiber, high temperature resistance, rapid heating and cooling)
5, boiler body through a fine spray corrosion of acid and alkali resistance, furnace body and the furnace wall temperature isolation by air-cooled furnace near room temperature
6, double circuit protection (temperature, pressure, flow, section I, super power etc.)
7, the material is imported refractory material, good insulation properties, high temperature resistance, heat shock resistance
8, temperature 1300 °C categories: 1400 °C of 1600 °C of 1700 °C 1800 °C five
Elevator electric large muffle furnace up to 1700 C
Specifications of elevator electric furnace
Temperature Project |
1600 deg |
Voltage AC |
380V |
Temperature Accuracy |
± 1 C |
Heating Element |
1800-type silicon molybdenum rod |
Furnace chamber dimension |
500*500*500mm |
Furnace temperature field uniformity |
± 1 C |
Temperature measurement devices |
Platinum and rhodium platinum B |
Refractory |
Lightweight materials imported Morgan |
Heating rate |
1/-1 degree |
Furnace temperature |
≤ 45 degrees |
The following models elevator furnace size can be customized (see special custom)
Furnace model |
Furnace temperature |
Furnace chamber size(D*W*H) |
Voltage AC |
Power |
KJ-1600 |
0—1600C |
300*300*300mm |
24KW |
380V |
KJ-1600 |
0—1600C |
300*300*500mm |
28KW |
380V |
KJ-1600 |
0—1600C |
400*400*400mm |
32KW |
380V |
KJ-1600 |
0—1600C |
400*400*500mm |
40KW |
380V |
KJ-1600 |
0—1600C |
500*500*500mm |
50KW |
380V |
