Home > Products > Stone Crusher Plant > High Professional 180TPH Aggregate Crushing Plant for Hard Rocks
High Professional 180TPH Aggregate Crushing Plant for Hard Rocks
- 500 Set / Sets per Month
- Qingdao Shanghai Tianjin China Main Ports
- T/T
- Tertiary Reversible Impact Hammer Crusher with High Chrome Blow Bar
- China Wheat and Grain Transport Vibrating Feeder Price in Shanghai
- Good Quality Heavy Hammer Crusher for Crushing All Kinds of Ores
- Sand Ore and Coal Vibrating Feeder Machinery Used in Mining Industry
- High Efficiency Stone Crushing Plant Impact Stone Crusher
- Sound Equipment Impact Crusher Machine for Stone Crushing Line
Product Details
Condition: | New | Type: | Other, stone crushing plant | Application: | Applied in primary and secondary crushing |
Motor Type: | AC Motor | Power(W): | 110kw | Capacity(t/h): | 150-200tph |
Place of Origin: | Henan, China | Brand Name: | ZOONYEE | Model Number: | 150-180T/H |
Certification: | CE, ISO9001:2000 | Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High Professional 180TPH Aggregate Crushing Plant for Hard Rocks
Introduction of 150-180 TPH Stone Crushing Plant
In comparison with 100-120TPH stone crushing plant, 150TPH-180TPH aggregate crushing plant is more competent when processing medium or over hard ores, especially while it is used for producing big aggregate.
All the machines applied in this production line work together and form a circle flow production line, which improve the efficiency and make the central control easier
Structure of stone crushing plant for quarry
Wide applications of Stone Crushing Plant
According to different customers’ requirements, stone crushing plant can be operated as two-stage crushing plant with primary and secondary crushing, or as three-stage crushing plant with primary, secondary, and tertiary crushing. Likewise, portable crushing plant can be easily adjusted to suit the crushing application by choosing feeding to crusher or feeding to screen options.
Reliable performance and convenient maintenance
150-180 TPH stone crushing plant adapt excellent quality crusher, screen and feeder made from Zoonye Industrial Company, yet the quality is stable and reliable. Normal belt conveyor can be used for conveyance of material, which is of mature technology, simply operation, easy maintenance, and low investment.
150-180 Stone Crushing Plant Process:
1. The primary jaw crusher PE750X1060 equips with stronger, enhanced jaw plates and larger feed opening, which increases the reduction ratio. In addition, thicker steel plate has been applied to main frame and flywheels, while the diameter of the flywheels are enlarged that greatly increased the weight of the machine, so when it works, the vibration is very slight but the crushing kinetic energy is very forceful.
2.The secondary crusher, impact crusher, is widely used and welcomed by users in lots of countries due to its high working efficiency.
3. For the purpose of improving finished products’ quality, water pipe or other washing equipments can be equipped upon filtrating equipments to clean the finished products.
4. Tertiary crusher such as VSI or others may work as additional processing machines to diversify the final products. Tailor-made dust catcher or dust cover can also be applied to this plant.
This production line calls for medium investment, you always get much more than you pay, it is the ideal choice for the clients.
Customized production and flexible configuration
We can provide special jaw crushing plant based on customers’ site, material, and particle shape requirements, etc. Such as self-load belt conveyor, multiple machines combined type, single machine type and so on.
Main Specification of 100-150 TPH Stone Crushing Plant
Main Components of 150-180T/H Stone Crushing Plant:
Vibrating Feeder ZSW 490 x110
Max Feeding Size: ≤630mm
Power: 15 kw
Jaw Crusher PE-750 X 1060
Max Feeding Size: ≤630mm
Power: 110kw
Impact Crusher PF-1315
Max Feeding Size: ≤500mm
Power: 220kw
Vibrating Screen 3YK1854
Sep1=40mm Sep2=20mm Sep3=5mm
Power: 22kw
Auxiliary Components of Stone Crushing Plant
Belt Conveyor
B800 X 17M
B800 X 20M
B500 x 22M
B500 X 16M
B500 X 16M
B500 X 16M
Control system
Electronic Control Cabinet
Zhengzhou Zoonyee Mining Machinery Co., Ltd are specialized in the research, production and sale of mining crushing equipment,sand making equipment and constuction waste recycling equipment.
Ourcompany always committed to providing the highgrade aggregate solution and advanced compete equipment for highway, railway,water and electricity engineering project.
From Different Countries -our customers
Installation in Algeria
in Kenya
Telephone : +86-371-63699132
FAX : +86-371-63935058
Mobile Phone:+008618703816563
Zhengzhou Zoonyee Machinery Co.,LTD
Ay questions please contact us freely.
