AsXSn Overhead Cable, 0.6/1 Kv, Al/UV-XLPE, ABC Cable (HD 626)
Core classification
Phase cores: Longtudinal ridges on the insulating coverings, in amount 1, 2, 3 pcs, visible with the naked eye and testable by touch,
Neutral core: Embossed marking with the cable name, crossection of phase and neutral cores, producer name, year, nominal voltage 0, 6/1 kV certification sigh (B),
Additional cores: One core - without ridges, two cores - on the second longtudinal ridge. The drawing blow desribe the core identification.
Construction
Phase cores, neutral additional cores made as aluminum multiwire compacted conductors with 7 or 19 wires. Aluminum wires parameters (before standing) acc to PN-EN 60889,
Insulation extruded from crosslinked poliethylene (XLPE) UV resistant. Insulation compound contain additional concentrate with extend resistance to fire propagation (tested acc. To PN-EN 6033
Wooden drums (size of the drum and cable lenghts should be agreed during ordering.
| No. of cores and cross-section | Shape of conductor | Nominal insulation thickness | Outer diameter approx. | Cable mass approx. |
| mm² | mm | mm | kg/km | |
| 1x16 | RMC | 1,2 | 7 | 66 |
| 1x25 | RMC | 1,3 | 9 | 98 |
| 1x35 | RMC | 1,3 | 10 | 134 |
| 1x50 | RMC | 1,5 | 12 | 185 |
| 1x70 | RMC | 1,5 | 13 | 241 |
| 1x95 | RMC | 1,7 | 15 | 328 |
| 1x120 | RMC | 1,7 | 17 | 401 |
| 2x16 | RMC | 1,2 | 15 | 134 |
| 2x25 | RMC | 1,3 | 17 | 198 |
| 2x35 | RMC | 1,3 | 20 | 271 |
| 4x16 | RMC | 1,2 | 18 | 271 |
| 4x25 | RMC | 1,3 | 21 | 399 |
| 4x35 | RMC | 1,3 | 24 | 545 |
| 4x50 | RMC | 1,5 | 28 | 754 |
| 4x70 | RMC | 1,5 | 32 | 981 |
| 4x95 | RMC | 1,7 | 37 | 1334 |
| 4x120 | RMC | 1,7 | 40 | 1633 |
| 4x25+25 | RMC | 1,3 | 21 | 500 |
| 4x35+25 | RMC | 1,3 | 24 | 646 |
| 4x35+35 | RMC | 1,3 | 24 | 683 |
| 4x35+2x25 | RMC | 1,3 | 24 | 748 |
| 4x50+25 | RMC | 1,5/1,3 | 28 | 855 |
| 4x50+35 | RMC | 1,5/1,3 | 28 | 892 |
| 4x50+2x25 | RMC | 1,5/1,3 | 28 | 957 |
| 4x50+2x35 | RMC | 1,5/1,3 | 28 | 1030 |
| 4x70+25 | RMC | 1,5/1,3 | 32 | 1083 |
| 4x70+35 | RMC | 1,5/1,3 | 32 | 1119 |
| 4x70+2x25 | RMC | 1,5/1,3 | 32 | 1185 |
| 4x70+2x35 | RMC | 1,5/1,3 | 32 | 1258 |
| 4x95+25 | RMC | 1,7/1,3 | 37 | 1435 |
| 4x95+35 | RMC | 1,7/1,3 | 37 | 1471 |
| 4x95+2x25 | RMC | 1,7/1,3 | 37 | 1537 |
| 4x95+2x35 | RMC | 1,7/1,3 | 37 | 1610 |
| 4x120+25 | RMC | 1,7/1,3 | 40 | 1735 |
| 4x120+35 | RMC | 1,7/1,3 | 40 | 1771 |
| 4x120+2x25 | RMC | 1,7/1,3 | 40 | 1834 |
| 4x120+2x35 | RMC | 1,7/1,3 | 40 | 1907 |
