Help CenterBamboo Powder Pellet Making Machine
Related Products
Specifications
1.easy operation2.higher safety and efficiency
3.energy saving
4.gearbox life
Bamboo powder pellet making machine. Skype:anna.jin29
It is mainly used to compress crushed corn straw, sawdust, plant waste, bamboo powder, grass, sunflower stalk, straw, rice husk, forestry waste, wood chips, chemical waste and ect. into cylindrical shape particles. Raw material moisture is 10%~15% before enter into pellet machine.The diameter of final size is 6mm, 8mm, 10mm, 12mm ect for the fuel pellet.
1.Feature:
Flat-die machine crude fiber is mainly applied to granulation. Such as
sawdust, rice husk, cotton stalk, cotton seed skins, weeds and crop stalks and other plant waste can also be applied to lio-fertilizer, organic manure, fertilizer, such as low-temperature granulation.
2.Function:
1) the use of technology: a unique three-in-one machines to complete low-temperature drying, cooling, screening the entire process. 2).Equipment: low investment and low operating costs.
3).Gear box life without refueling.
3. technical data
model |
Output(kg/h) |
Power(kw) |
Particle specification(mm) |
Dynamic configuration |
Size(mm) |
Weight(packaged)(kg) |
250 |
500/1000 |
22+1.5+0.55/22 |
3-8 |
Triangle-generation |
1650*1500*1550 |
1000 |
260 |
600/1500 |
22+1.5+0.55/22 |
3-8 |
Triangle-generation |
1650*1500*1550 |
1200 |
300 |
800/2000 |
30+1.5+0.55/30 |
3-8 |
Triangle-generation |
1750*1500*1600 |
1500 |
350 |
1000/3000 |
30+30+2.2+0.75/60 |
3-10 |
Gear box |
2300*1500*2200 |
2000 |
420 |
2000/5000 |
90+2.2+1.1/90 |
3-12 |
Gear box |
2500*1200*2300 |
3000 |
508 |
2000/8000 |
110+2.2+1.1/32 |
3-15 |
Gear box |
2500*1300*2400 |
3800 |
4.Spare psrts
5. Final pellets
6.Raw material
