Conveyor feeding rotary sifter for sawdust(1)Good design!
(2)Resonable price!
(3)High efficiency!
(4)competitive price
Conveyor feeding rotary sifter for sawdust
I. Working Principle:
1.Conveyor feeding rotary sifter for sawdust is a kind of feeding machine which takes the powder, nubby, uncrushed or impurity material out of the raw material.
2.The working principle of Conveyor feeding rotary sifter for sawdust : electric motor transfer the power to main drive shaft through vee belt, then main drive shaft drive the sifter net to whirl to pick the nubby and impurity up so as to ensure the safety and effective production in the briquetting course.
II. Structural features of Conveyor feeding rotary sifter for sawdust:
1. Tactical diameter of Conveyor feeding rotary sifter for sawdust is large, feed quickly, driven rotation of small diameter, less power.
2. Screen stencil and body of Conveyor feeding rotary sifter for sawdust are connected with rigidity, the concentricity is high, and machine is stable.
3. V-belt drive, smooth operation, low noise.
4. Based on customer needs, we design two kinds of models: manual feeding rotary sifter and conveyor feeding rotary sifter.
The specification of Conveyor feeding rotary sifter for sawdust:
Name |
Type |
Power |
Capacity |
Dimension |
GTS612 |
Manual power feeding |
0.75kw |
1.2t |
1.6m*0.8m*1.3m |
GTS612 |
Conveyor feeding |
0.75kw |
1.2t |
1.6m*0.8m*1.8m |
The show of Conveyor feeding rotary sifter for sawdust:
