Sawdust rotary trommel screen

Specifications

Sawdust rotary trommel screen
(1)Two types:conveyor feeding , mannual feeding!
(2)Competitive price!
(3)good appearance



Sawdust rotary trommel screen



Working Principle:



Meterial applied : powder, nubby, uncrushed or impurity material out of the raw material.

The working principle: electric motor transfer the power to main drive shaft through vee belt, then main drive shaft drive the sifter net to whirl to pick the nubby and impurity up so as to ensure the safety and effective production in the briquetting course.

Structural features:

1. Large diameter , feed quickly, driven rotation of small diameter, saving the power.

2. Screen stencil and body are connected with rigidity, the concentricity is high, and machine is stable.

3. V-belt drive, smooth operation, low noise.



Technical data:

Product	Model	Feeding type	Power (KW)	Capacity (T/h)	dimension(m)	Sieve pore(mm)
Sifter	GTS612	Manual feeding	0.75-4 pole	1—2	1.6X0.8X1.3	7X7
	GTS612	Automatic feeding	0.75-4 pole	1—2	1.6X0.8X1.8	7X7
