AAAC Conductor, All Aluminium Alloy Conductor (DIN 48201-6)
US$ 0.25 - 15
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DingAn
Model Number:
AAAC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ACSR, Aluminium Conductors Steel Reinforced (JIS C 3110)US$ 1 - 5MOQ: 500 Meters -
AAC Conductor, Type A Wire, All Aluminium Conductor (GOST 839-80)US$ 0.3 - 20MOQ: 500 Meters
-
ACSR, Type AC, Aluminium Conductors Steel Reinforced (GOST 839-80)US$ 1.19 - 10MOQ: 500 Meters
-
HDBC, Stranded Bare Copper Conductor (DIN 48201-1)US$ 0.5 - 18MOQ: 5000 Meters
-
ACSR Type Asx All-Greased Aluminium Conductors Steel Reinforced GOST 839-80US$ 1.19 - 12MOQ: 500 Meters
Place of Origin
Jiangsu, China
Brand Name
DingAn
Model Number
AAAC
Type
Low Voltage
Application
Overhead
Conductor Material
Aluminum
AAAC Conductor, All Aluminium Alloy Conductor (DIN 48201-6)
Applications
Conductor(AAAC) have been widely used in power transmission lines with various voltage levels, and also used in power lines across great rivers, heavy ice area, and other places special geographical characteristics. The conductor have excellent advantages of high strength, large current carrying capacity and good catenary property as well as wear-resistance, anti-crush and corrosion-proof with simple structure, convenient installation and maintenance, low cost for the line, large transmission capacity.
Specifications
Conductor(AAAC) bear conductor meets or exceeds the following Specifications:
DIN 48201-6
| Nominal Area | Conductor Construction | Calculated Area | Overall Diameter | Weight | DC Resistance at 20 |
| mm2 | No./mm | mm2 | mm | kg/km | Ω/km |
| 16 | 7/1.70 | 15.9 | 5.1 | 43.5 | 2.091 |
| 25 | 7/2.10 | 24.2 | 6.3 | 66.4 | 1.370 |
| 35 | 7/2.50 | 34.4 | 7.5 | 94.1 | 0.9669 |
| 50 | 7/3.00 | 49.5 | 9.0 | 135 | 0.6714 |
| 50 | 19/1.80 | 48.3 | 9.0 | 133 | 0.6905 |
| 70 | 19/2.10 | 65.8 | 10.5 | 181 | 0.5073 |
| 95 | 19/2.50 | 93.3 | 12.5 | 257 | 0.358 |
| 120 | 19/2.80 | 117 | 14 | 322 | 0.2854 |
| 150 | 37/2.25 | 147 | 15.7 | 406 | 0.2274 |
| 185 | 37/2.50 | 182 | 17.5 | 501 | 0.1842 |
| 240 | 61/2.25 | 243 | 20.2 | 671 | 0.1383 |
| 300 | 61/2.50 | 299 | 22.5 | 828 | 0.1120 |
| 400 | 61/2.89 | 400 | 26.0 | 1,106 | 0.0838 |
| 500 | 61/3.23 | 500 | 29.1 | 1382 | 0.06709 |
| 625 | 91/2.96 | 626 | 32.6 | 1,735 | 0.05367 |
| 800 | 91/3.35 | 802 | 36.9 | 2,222 | 0.0419 |
| 1000 | 91/3.74 | 1,000 | 41.1 | 2,770 | 0.03362 |
