2014 New CE Certificated China Wet Grinding Mill

2014 New CE Certificated China Wet Grinding Mill thumbnail-1
2014 New CE Certificated China Wet Grinding Mill thumbnail-2
2014 New CE Certificated China Wet Grinding Mill thumbnail-3
2014 New CE Certificated China Wet Grinding Mill photo-1
2014 New CE Certificated China Wet Grinding Mill photo-2
2014 New CE Certificated China Wet Grinding Mill photo-3
US$ 2,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Zhengzhou Zoonyee Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Power(W) 240kw
Capacity(t/h) 18.5-8.7
Place of Origin Henan, China
Brand Name zoonye
Model Number MQ2430
Dimension(L*W*H) 2400*3000mm
Certification CE, ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Wet Grinding Mill
Grinding various ore and other grindable materials dry or wet
Stable running and reliable working

2014 New CE Certificated China Wet Grinding Mill









Product Description





Introduction of  Wet Grinding Mill

Wet grinding mill is mainly used for grinding materials in such production industries as cement, silicate product, new building materials, chemical engineering, nonferrous and black metal, mineral processing, glass and ceramic, etc. It is used for grinding various ore and other grindable materials dry or wet.



Structural Feature of  Wet Grinding Mill
Ball grinding mill is a principle and cylindrical revolving device, and belongs to external gear-driving ball mill. The materials are transported by feeder, and gets into mill chamber through hollow screw axis equably, and there is lining plate and steel balls in the chamber. When the cylinder body goes round and round, the steel ball is taken to certain height, then falls down, and the materials are struck and grinded heavily. The above action repeats constantly till the size of materials reaches the required fineness. The powdery materials are discharged through discharge grate plate, and the milling work is over.
 Ball mill mainly consists of feeding part, discharging part, gyre part, transmission part (decelerated machine, small transmission gear, motor, electric control) and so on. The hollow axis adopts cast steel, the lining plate can be replaced, the big gyre gear is made of forging rolling gear, and there is lining plate in the cylinder body, which has favorable abrasion resistance. The ball mill has the features of stable running and reliable working.



Specification of  Wet Grinding Mill



Type



Model



Drum (mm)





Volume (m3)



Revolution (r/min)



Motor (KW)



Discharging Size (mm)



Output (t/h)





Wet-Grate

Ball

Mills



MQ1530

1500×3000

4.5

26.5-29.8

95

0.3-0.074

6.1-3.1

MQ2130

2100×3000

9.2

22.2-25.2

210

0.3-0.074

14-6.4

MQ2430

2400×3000

12.2

20.8-23.5

240

0.3-0.074

18.5-8.7

MQ2736

2700×3600

18.4

19.6-22.2

400

0.3-0.074

28-13

MQ3245

3200×4500

32.8

18-20.4

800

0.3-0.074

49-24

MQ3660

3600×6000

54.4

17-19.2

1600

0.3-0.074

82-38

Dry-Grate Ball

Mills





MQG1515

1500×1500

2.2

26.5-29.8

60

0.4-0.074

5.2-1.9

MQG1522

1500×2250

3.4

26.5-29.8

75

0.4-0.074

10.2-2.7

MQG1530

1500×3000

4.5

26.5-29.8

95

0.4-0.074

14-3.6

MQG2122

2100×2200

6.7

22.2-25.2

155

0.4-0.074

25-5

MQG2424

2400×2400

9.8

20.8-23.5

210

0.4-0.074

29-7.5

MQG2430

2400×3000

12.2

20.8-23.5

240

0.4-0.074

38-9.5

Over-flow Ball

Mills





MQY1530

1500×3000

4.5

26.5-29.8

95

0.3-0.074

6-2.8

MQY2136

2100×3600

11

19-25.2

210

0.3-0.074

12.8-6

MQY2430

2400×3000

12.2

17.8-23.5

240

0.3-0.074

16.6-7.8

MQY2740

2700×4000

20.4

16.8-22.2

400

0.3-0.074

27.7-13

MQY3254

3200×5400

39.4

15.5-20.4

1000

0.3-0.074

52.8-25.9

MQY3660

3600×6000

54.4

14.5-19.2

1250

0.3-0.074

74.1-32.4



2014 New CE Certificated China Wet Grinding Mill2014 New CE Certificated China Wet Grinding Mill2014 New CE Certificated China Wet Grinding Mill2014 New CE Certificated China Wet Grinding Mill




Packaging & Shipping



  • Packaging: Standard Container, Nude Packs or in Bulk.
  • Shipping: we deliver the cargo to China's main sea ports,such as Qingdao,Tianjin,Shanghai etc.And then the container will be transported to your country by sea.





Our Services





1.more than 12 months' warranty period
2.Erection and Commissioning
3.Operator Training
4.Spare Parts Supply





China wet grinding mill for sale with low price and good quality.
