(Manufactory) 2400MHz 16dB Directional Panel Antenna
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JIASHANJINCHANG
Model Number:
JCP-2400-16
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
(Manufactory) 2400-2500Mhz 15dBi Panel AntennaNegotiableMOQ: 10 Pieces -
(Manufactory) 1710-2170MHz Indoor UHF Signal AntennaNegotiableMOQ: 10 Pieces
-
(Manufactory) 2.4GHz Directional 18dBi Panel AntennaNegotiableMOQ: 10 Pieces
-
(Manufactory) 1710-2170MHz 3G Panel AntennaNegotiableMOQ: 10 Pieces
-
(Manufactory) 3G High Gain Panel AntennaNegotiableMOQ: 10 Pieces
Place of Origin
Zhejiang, China
Brand Name
JIASHANJINCHANG
Model Number
JCP-2400-16
Specifications
Size: 454*134*30mmFrequency: 2400-2483 MHz
Gain: 16dBi
Connector: N Female
High Gain
Directional Panel Antenna
Features
High Gain
H or V Polarization
Full day for working
Durable, corrosion resistance
Optimized dimension
Application
2.4 GHz WIFI WLAN System
2.4GHz ISM applications
Public wireless hot signal coverage
Wifi system
|
JCP-2400-16 Electric Specifications | |
Frequency rang |
2400-2483 |
Bandwidth -MHz |
83 |
Gain(DBi) |
16 |
Beamwidth(0°) |
H 65 V 15 |
Input Impedance(Ω) |
50 |
VSWR |
≤1.5 |
Polarization |
Vertical |
Max power(W) |
100 |
Lightning protection |
DC Ground |
Connector model |
N Female |
Mechanical Specifications | |
antenna size (mm) |
454*134*30 |
Antenna weight (kg) |
1.9 |
Radome material |
ABS |
Working Temperature(°c) |
-40~60 |
Rated Wind Velocit(m/s) |
60 |
Pole diamete(mm) |
50~75 |
