Help CenterHOT Leather Splitting Machine JD-300
Related Products
use
The machine adapts to splitting the hard or soft leather symmetrically, which the width is less than 300mm,according to the required thickness in the industry of leather products.
CHARACTERS
1.Indicate the splitting thickness by number,the infinitely variable adjustment of feeding.,
2.With automatic feed registration device, no need to adjust cutting tool.
3.Adjust the clearance of pressure pad and cutting tool automatically to make the splitting precision much higher.
4.Freestanding set of dust absorbing and indication function when ash-bin is full.
5.With function of dropping out when feeding, leather material entangles automatic pause system of roller.
6.Automatic detection system of electronic phase makes the machine runs to veering direction.
7.The accurate rail makes the movement of flying wheel more reliable, and the replacement of band knife more easy, quick and convenient.
8.Splitdifferent leather,pressure of splitting can be adjusted automatically.
9.Automatic indication when door board closed up, reliable 8mm finger safe protection set.
10.Emery wheel grinding system will be much higher precision of knife-edge,more smooth section and more durable knife tool by using diamond grinding wheel.
| mode type | JD-300 |
| maximal width of split | 300mm |
| cut thinkness | adop feeding pole:0.2-8mm |
| minimum cutting thickness | 0.2mm |
| rotate spped of grinding wheel | 4000rpm |
| speed thread of band kinfe | 183m/min |
| feeding speed | stepless timing |
| knife specification | 2630*50*0.6mm |
| moto power | 3.2kw |
| exterior size | 1210*850*1010mm |
| parking size | 1430*1100*1250mm |
| net wieght | 577kg |
| gross weight | 669kg |
