Original Aodisen 3 Inch 178F 6.5hp 296cc Diesel Engine, 80mm, Hand Start,portable Agriculture Diesel Water Pump

Original Aodisen 3 Inch 178F 6.5hp 296cc Diesel Engine, 80mm, Hand Start,portable Agriculture Diesel Water Pump photo-1
US$ 225 - 275 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Aodisen
Model Number:
DP50B
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/ Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Aodisen
Model Number DP50B
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Water
Power Other, engine pump
Standard or Nonstandard Standard
Fuel Diesel
Pressure High Pressure
Application Other, home, garden, agriculture

Original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start, portable agriculture diesel water pump

PRODUCT DESCRIPTION

- Features

1. Portable compact open structure
2. Economical, reliable and durable
3. Long run time - up to 13.5 hours
4. AVR to automatically regulate voltage
5. Oil alert to shut down engine automatically when low oil is detected
6. Circuit breaker to stop engine automatically when overloaded
7. Powers fridge, furnace, lights, TV, computer, and much more



original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



Optional 1: brown carton or color carton optional

Optional 2: plastic or aluminum nipples / connector and flanges optional

Tell us your detail requirement, to recommend you the right one





TECHNICAL DATA

Model DP80B   3 inch

Model DP0B
Delivery (mm) 80 (3')
Suction (mm) 80 (3')
Max. delivery volume(m3/h) 50
total head (m) 25
suction head (m) 8
diesel engine model 178F/FE
bore*stroke (mm*mm) 78*62
displacement (cc) 296
diesel engine type air-cooled, 4-stroke, vertical, single-cylinder, direct injection combustion
governor system all-speed type, mechanical governor
Max. poer output (hp) 6.5HP
compression rate 20:01
ignition systems explode ingition
lube oil system pressure splash type
starting system recoil or electric
Lube oil capacity (L) 1.1
feul tank capacity (L) 3.5
L*W*H (mm) 580*470*550
Loading Quantity 192
N.W/ G.W (kg) 48/50



Alternator: high quality alternator (copper wire and aluminum wire optional)

Starting: recoil start, with electric start optional (7Ah or 9Ah battery)

Optional: 8''/10" rubber or solid wheels & 2 handles

Tell us your detail requirement, to recommend you the right one



FACTORY SHOW

- Sample Room

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



- Raw Material

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



- Assembly

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



- Test

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



- Packing

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



- Loading

 original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



customer

original Aodisen 3 inch 178F 6.5hp 296cc diesel engine, 80mm, hand start,portable agriculture diesel water pump



1 inch - 4 inch Diesel water pump

Professional generator manufacturer with R&D capacity

Reliable quality, reasonable price, desirable service

Tell us your demand, provide what you want

Contact us now, let's make a deal.........
