braided shield wire 24awg utp cat5e unshielded patch cord
Introduction
What is cat5e cable?
CAT5e is an Ethernet cable standard defined by the Electronic Industries Association and Telecommunications Industry Association (commonly known as EIA/TIA). CAT5 is the sixth generation of twisted pair Ethernet cabling.
Specification
1.Conductor Material: BC/CCA/CCS/CCAM
2.Conductor Dia:0.50mm+/-0.02mm
3.Insulation: 0.88mm+/-0.02mmPE
4.Jacket: 5.2mm+/-0.2mmPVC
5.Rip cord: Optional
6.Drain wire: Optional
7.Rated Temperature: 60 degrees 75 degrees
8.Ripcord: Optional
Pair 1 Orange and orange white
Pair 2 Blue and blue white
Pair3 Green and green white
Pair4 Brown and brown white
Electrical Specfications
Dielectric strength |
2.5kv dc-2seconds |
Conductor resistance |
Max 9.38ohm/100mt at 20°C |
Max ring resistance |
16.8ohm/100mt at 20°C |
Max mutual capacitance |
560pf/100mt |
Max capacity unbalance |
330pf/100mt |
Impedance |
100+/-15% at 1~100MHz |
Picture shows:
1. Your inquiry related to our products or price will be replied in 24 hours.
2. Well-trained and experienced staffs to answer all your enquires in fluent English.
3. OEM/ODM is welcomed, any your customized points, we can help you to design and put into product.
4. Protection of your sales area, ideas of design and all your private information.
