Network cable :Solid 24AWG fire resistant cat5e cable
Introduction
A Cat 5e (Category 5e) Cable is an Ethernet network cable standard that consists of four twisted pairs of copper wire terminated by RJ45 connectors. It is based on the EIA/TIA 568 Commercial Building Telecommunications Wiring Standard developed by the Electronics Industries Association.
Cable Structure Details
1.Conductor:
Material: solid BC,CCA,CCS,CCAM
Numbers of pairs: 4 pairs (8 wires )
AWG:24AWG
Conductor diameter: 0.51mm+/-0.02mm
2.Insulation:
Material: PE or HDPE
Diameter: 0.91mm+/- 0.02mm
Average thickness: 0.212mm
Minimum thickness: 0.2095mm
3.Sheath:
Material: PVC
Diameter: 5.2mm+/-0.2mm
Electrical Specifications
Dielectric strength |
2.5KV dc-2seconds |
Conductor resistance |
Max 9.38ohm/100M at 20°C |
Max. ring resistance |
16.8 ohm/100M at 20°C |
Max. mutual capacitance |
560 pf/100M |
Max. capacity unbalance |
330 pf/100M |
Standard impedance |
100±15 ohm between 1Mhz and 100Mhz |
Minimum bending radius |
60mm |
Working temperatures |
-20~60°C |
DTX1800 Fluke Link test |
100% pass 90meters Link test |
Network Analyzer |
100% pass 305meters network analyzer test |
