Power Supply Cabinet HV Switchgear Power Equipment
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
NingGrand
Model Number:
power supply cabinet HV switchgear power equipment
Payment & Shipping
Payment Methods:
Port of Shipment:
all ports
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Sichuan, China
Brand Name
NingGrand
Model Number
power supply cabinet HV switchgear power equipment
Product Description
power supply cabinet HV switchgear power equipment
1.Outline
KYN61-40.5 (Z) armored remove AC metal-enclosed switchgear (hereinafter referred to as switchgear) the amount of three-phase AC 50Hz, rated voltage 40.5KV indoor power distribution equipment. As power plants, substations and industrial and mining enterprises to accept and distribution of electric energy, to play a control circuit, protection and detection and other functions, but also for frequent operation place.
The switch cabinet in line with GB / T11022-1999, GB3906-1991 and DL404-1997 standards.
2.Main features
1, the use of assembled cabinet structure, off the floor structure uses a handcart;
2, equipped with a new type of composite insulated vacuum circuit breakers, and replace with a simple interchangeability of characteristics;
3, handcart rack mounted mechanical wire nut propelling mechanism, can be easily moved handcart, and to prevent misuse and promote structural damage;
4, all operations can be carried out in a state where the door closed;
5, the main switch, handcart, door interlock switches are made between the mandatory mechanical locking methods to meet the "Five Anti" feature;
6, electricity ample room space can connect multiple cables;
7, speed grounding switch for grounding and short-circuit loop;
8, shell protection grade IP3X, handcart door open state, protection class IP2X;
9, the products meet GB3906-1991, DL404-1997 and reference to the use of international IEC-298 standards.
3.Environmental conditions
1, ambient temperature: up to + 40 ℃, and the average temperature measured over 24h does not exceed into 35 ℃, lower limit of -10 ℃.
2, Altitude: not exceed 1000m.
3, relative humidity: daily average of not more than 95%, on average less than 90%.
4. Earthquake intensity: not more than 8 degrees.
5, the water vapor pressure: daily average of not more than 2.2KPa on average less than 1.8KPa..
6, the surrounding environment: no fire, explosion, severe contamination, chemical corrosion and severe vibration.
Technical parameters
Vacuum switchgear main technical parameters
| No. | Name | Unit | Value |
| 1 | Rated voltage | KV | 40.5 |
| 2 | Rated current | A | 630 1250 1600 2000 |
| 3 | Rated frequency | Hz | 50 |
| 4 | Rated short time withstand current | KA | 20 25 31.5 |
| 5 | Rated peak withstand current | KA | 50 63 80 |
| 6 | Rated power frequency withstand voltage | KV | 95/min |
| 7 | Rated lightning impulse withstand voltage | KV | 185 |
| 8 | Rated short circuit duration | S | 4 |
| 9 | Protection class | IP3X |
Vacuum circuit breaker main technical parameters
| No. | Name | Unit | Value |
| 1 | Rated voltage | KV | 40.5 |
| 2 | Rated frequency | Hz | 50 |
| 3 | Rated power frequency withstand voltage | KV | 95/1min |
| 4 | Rated lightning impulse withstand voltage | KV | 185 |
| 5 | Rated current | A | 630 1250 1600 2000 |
| 6 | Rated short time withstand current | KA | 20 25 31.5 |
| 7 | Rated short circuit breaking current | KA | 20 25 31.5 |
| 8 | Rated peak withstand current | KA | 50 63 80 |
| 9 | Rated short circuit duration | ms | 4 |
| 10 | Opening time | ms | 30≤t≤60 |
| 11 | Closing time | S | 50≤t≤100 |
| 12 | Rated short circuit breaking current times | time | 20 |
| 13 | Mechanical life | time |
10000 |
Spring operating machinery main technical parameters
| ||||||||||||||||||||||||||||
Switchgear structural features
Switchgear according to GB3906-1991 and IEC298 Kai mounted in metal-enclosed switchgear standard designed overall by the cabinet and can be removed from part (handcart) composed of two parts. Cabinet structure for the group and Syria, in combination with bolted molding. Metal screens inside the switchgear divided into circuit breaker compartment, main bus room, cable room and relay instrument room. Shell protection grade IP3X, among compartment protection class IP2X, and all grounded metal structure, each compartment main loop exhaust system with separate pressure release channel.
1, the housing and the separator
Switchgear shell and bulkhead are quasi-rolled steel sheet after several control machining and after bending bolted together. Thus assembled switchgear to ensure the unity of the structure size. Switchgear was divided circuit breaker compartment, main bus room, cable room and relay meter room, each portion of a metal plate connected to separate.
2. Used
Used according to the application can be divided into circuit breaker, voltage transformer handcart, metrology handcart, isolating handcart, etc., all kinds of handcarts same dimensions, the same purpose handcart interchangeability. Used in the cabinet have the test / disconnected position and the working position, every position has interlock device to ensure when the trolley can not move in just over two positions.
3, the circuit breaker compartment
Breaker compartment installed in a specific track for the trolley to move. Breaker moves, isolation valve is automatically opened or closed position between the test position and work to protect the staff do not touch live body. Handcart can be operated in case the door closed, the window can be seen by observing the position of the trolley cabinet which also function to see any signs on the trolley.
4, busbar chamber
Main line from one switch to another switchgear cabinet lead by a small line of static contact box branch fixed pipe fixing bus when crossing the adjacent cabinet side. All bus composite insulated manner.
5, the cable compartment
Cables can be installed indoors PT, grounding switch and surge arresters multiple cables.
6, relay room
Relays interior panels and control panel can be installed to protect the element, the second element measurement instrument display, live monitoring displays.
7, interlocks
Switchgear has a reliable interlock device, effectively protect the safety of operating personnel and equipment T;
When the grounding switch is in the OFF position, the trolley to and grounding switch interlock unlocked from the test / disconnected position, earthing switch closing operation can be carried out; handcart position at work, can not be closed grounding switch. Prevent the charged closing earthing switch, grounding switch prevented in the closed position when the trolley moves to the working position.
Used off the device in the test / disconnected position or working position, in order to operate the circuit breaker, and the circuit breaker after closing, the trolley can not move to prevent the live load mistakenly push-pull circuit.
Each cabinet can be installed between the electrical interlock.
8, the grounding device
In the cable compartment, alone with a 6 × 50mm2 ground bus, this bus can penetrate adjacent each cabinet, good contact with the cabinet.
Switchgear Dimensions
