High Voltage Bellows Pipe Compensator Power Saver Device

High Voltage Bellows Pipe Compensator Power Saver Device thumbnail-1
High Voltage Bellows Pipe Compensator Power Saver Device thumbnail-2
High Voltage Bellows Pipe Compensator Power Saver Device photo-1
High Voltage Bellows Pipe Compensator Power Saver Device photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
NingGrand
Model Number:
power saver device
Contact Supplier Request Quote Chat Now
NingGrand Electric Inc.
Payment & Shipping
Payment Methods:
Port of Shipment:
all ports.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name NingGrand
Model Number power saver device
Product Description

 High voltage bellows pipe compensator power saver device

High voltage bellows pipe compensator power saver device

1, Outline



   With the development of the national economy, various industries and civil loads are significantly increased, the new load current increases in reactive load power system losses, so to be on the grid reactive power compensation. NTBB sets of high-voltage shunt capacitor device consists of high voltage switchgear, shunt capacitor, series reactor, consisting of zinc oxide surge arresters, discharge coil, post insulators, grounding switch. Fuse in series with the capacitor device, when some internal capacitors in series segment breakdown, the fuse action, the Taiwanese capacitor rapidly excised from the capacitor bank, effectively prevent the failure to expand. Discharge coil shunt capacitor circuits, when the group launched the run from the power supply capacitor, the voltage on the capacitor to make a reputation within 5 seconds since the peak rated voltage drops below 50V. MOA and connect the line to limit the switched capacitor caused by over-voltage operation. Series reactors in series with the capacitor circuit to limit the switching capacitor banks in high harmonics, reduce inrush current.



2,  Type meaning



High voltage bellows pipe compensator power saver device

3,Normal conditions of use



1   Ambient air temperature: -20 ℃ ~ + 45 ℃;

2 does not exceed 95% relative humidity
3 altitude less than 2000m
4 maximum operating voltage does not exceed 110% of the rated voltage (excluding transition process)
5 maximum load current does not exceed 130% of the rated current (excluding transition process)
Around 6 medium without danger of explosion and flammable, non-corrosive metal enough to damage the insulation and gas, non-conductive dust
7 installation site without severe vibration and bumps, installation tilt is not greater than 5 °
8 power supply in line with national standards, there is no strong harmonics



 4,Main technical parameters

Product Model Rated capacity(Kvar) Rated voltage(kV) Reactor structure A single three-phase capacitor capacity(kvar) overall dimensions
(LXWXH mm)
NTBB-6-800/200 800 6 Iron Core 250X4 3200X1200X2600
NTBB-6-1000/250 1000 6 Iron Core 250X4 3200X1200X2600
NTBB-6-1200/300 1200 6 Iron Core 300X4 3200X1200X2600
NTBB-6-1400/350 1400 6 Iron Core 350X4 3200X1200X2800
NTBB-6-1800/300 1800 6 Iron Core 300X6 3600X1200X2600
NTBB-6-2000/500 2000 6 Iron Core 500X4 4800X1200X2200
NTBB-6-2100/350 2100 6 Iron Core 350X6 3800X1200X2200
NTBB-6-2400/300 2400 6 Iron Core 300X8 4800X1200X2600
NTBB-6-2800/350 2800 6 Iron Core 350X8 4800X1200X2800
NTBB-6-3000/550 3000 6 Iron Core 500X6 6000X1200X2200
NTBB-10-300/200 800 10 Iron Core 200X4 3200X1200X2800
NTBB-10-1000/250 1000 10 Iron Core 250X4 3200X1200X2800
NTBB-10-1200/300 1200 10 Iron Core 300X4 3200X1200X2600
NTBB-10-1400/350 1400 10 Iron Core 350X4 3200X1200X2800
NTBB-10-1800/300 1800 10 Iron Core 300X6 3600X1200X2600
NTBB-10-2000/500 2000 10 Iron Core 500X4 4800X1200X2200
NTBB-10-2100/350 2100 10 Iron Core 350X6 3800X1200X2800
NTBB-10-2400/300 2400 10 Iron Core 300X8 4800X1200X2600
NTBB-10-2800/350 2800 10 Iron Core 350X8 4800X1200X2800
NTBB-10-3000/500 3000 10 Iron Core 300X6 6000X1200X2200
