ASTM H21/JIS SKD5/DIN X30WCrV9-3
This steel can be used to produce high temperature high stress, but not by impact load of convex die, die such as horizontal forging machine with the punch,
insert, copper alloy extrusion die, die casting dies, such as anti - extrusion die; but also can be used as a hot metal under high temperature stress of the cutter.
Do the mold steel tungsten containing heat, the steel Mo content increased 2%, adding proper amount of Mn content, improve the high temperature mechanical
properties of steel, to adapt to the need of mass production of aluminum alloy die casting mold. It has high heat resistance, high thermal stability of the steel,
wear resistance and good process performance, working temperature reached 650 degrees centigrade.
Product Basic Information:
Material |
ASTM H21 |
||
Chemical Composition |
Mechanical Properties(In Quenched & Tempered State) |
||
C |
0.26-0.36 |
Tensile strength(MPA) |
≥1078 |
Si |
0.15-0.50 |
Yield strength (MPA) |
|
Mn |
0.15-0.40 |
Elongation(δ5/%) |
≥9 |
B |
- |
Reduction in Area (ψ/%) |
≥45 |
Mo |
- |
Impact (J) |
- |
P |
- |
Hardness |
≤235HB |
S |
- |
||
Cr |
3.00-3.75 |
||
W |
8.5-10.0 |
||
V |
0.30-0.60 |
||
Cu |
- |
||
N |
- |
||
2.Product Application Areas:
Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical industry,
electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.
3.Similar steel grade & equivalent steel materials:
USA |
Japanese |
Gemany |
British |
France |
International |
Chinese |
ASTM&AISI&SAE |
JIS |
EN DIN |
EN BS |
EN NF |
ISO |
GB |
H21 |
SKD5 |
X30WCrV9-3 |
X30WCrV9-3
|
3Cr2W8V
|
||
High strength and resistance to intergranular corrosion and chloride stress corrosion is improved obviously. Stainless steel has great corrosion performance.
Product Sales Information:
Grade |
H21 Tool Steel |
Size |
Diameter:0.5-8mm |
Origin place |
Made In China |
Delivery Condition |
Hot rolled,cold drawn,forged |
Surface require |
Black,grinding,bright,polish |
Heat treatment |
Quenched,Tempered,annealed |
Packing |
seaworthy packing ,wooden case ,carton,woven bag or at client's requires |
Delivery time |
In 10-50 days |
Trade Term |
EXW,FOB,CIF |
Payments |
T/T or L/C at sight |
Port |
China main Port,such as shanghai,Dalian,Shenzhen port. |
MOQ |
1 Ton |
Company Main Products:
Alloy Steel |
5140,5115,5120,5130,5145,4118,4130,4135,6150,5115,4142,4130,4118,6150,4140,4720,4320 ,E9310,8620,4340 |
Tool Steel |
H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419, SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2 |
Bearing Steel |
GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50 |
Spring Steel |
9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150, SUP10,51CrV4,1.8159 |
Stainless Steel |
321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028, 434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057,201,202,301 |
