[RD-A1200-2400]Automatic Lead Edge Feeding Rotary Die Cutting Machine

Pujiang Ruida Industry & Trade Co., Ltd.
[RD-A1200-2400]Automatic Lead Edge Feeding Rotary Die Cutting Machine thumbnail-1
[RD-A1200-2400]Automatic Lead Edge Feeding Rotary Die Cutting Machine photo-1
US$ 1,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Machinery & Hardware
Packaging Type:
Case
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, Machinery & Hardware
Packaging Type Case
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 380V
Power 4KW
Place of Origin Zhejiang, China
Brand Name RUIDA
Model Number RD-A1200-2400
Dimension(L*W*H) 4300x2800x2000mm
Weight 6T
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

- Numerical control and lead edge feeding
- High quality & best service
- Competitive price
- Easy operation & maintenance

                              Automatic lead edge feeding rotary die cutting machine







 [RD-A1200-2400]Automatic lead edge feeding rotary die cutting machine





Features



  • NC control unit
    • Human-computer interface design, equipped with high precise and complete numerical PLC control system.
    • Main machine is driven by frequency conversion motor.
    • Front and rear control panels are concisely concentrated and operated conveniently.
    • The machine is combination controlled by light, electricity and compressed air.
    • All the electrical components are in according with the international standard and named brand.
  • Paper feeding unit
    • Automatic adsorption lead edge feeding cardboard, the feeding speed reaches to more than 160pcs/min with the die cutting precision of ±0.75mm.
    • The phase position is electrical adjusted by planetary gear, it's able to adjust when starting up and shutting down.
    • The front panel is manual adjusted while the side panel is adjusted by electrical automatically.
    • The paper transmission roll equipped with a rubber surface to prevent crushing the cardboard, and improve the transmission accuracy.
  • Die cutting unit
    • The slotting, corner cutting, creasing and punching will be accomplished in one time.
    • The main structure and frame is made of high quality cast iron, with the thickness of 50mm.
    • The die cutting roller is made of the high quality steel with the thickness of 30mm, and chrome plated, as well balance adjustment.
    • Die cutting roller cylinder type auto separation unit can increase wear of rubber sleeve.
    • Mechanical soft roll is able to lateral movement for 40mm, to make the rubber wear evenly.
    • The soft roller auto self grinding unit improves the usage of rubber sleeve, 3 or 4 times grinding and re-use is available.
    • Automatic compensation of linear velocity can guarantee that die-cutting size for each batch of cartons is in full accord.
    • America imported polyurethane rubber is easy and convenient to install and has a long lifetime, able to die cutting for 12 million times.
    •  The transmission gear is made of high quality steel with the treatment of accurate grinding, has the advantage of low noise and long lifetime.



Specification





Model

Max. paper size

Min. paper size

Cardboard thickness

Max. design speed

Power

Weight

mm

mm

mm

pcs/min

kw

kg

RD-MQA1200-1600

1200*1600

350*500

11

120

4.0

4000

RD-MQA1200-1800

1200*1800

350*500

11

120

4.5

4500

RD-MQA1200-2000

1200*2000

350*500

11

120

5.0

5000

RD-MQA1200-2200

1200*2200

350*500

11

120

5.5

5500

RD-MQA1200-2400

1200*2400

400*500

11

120

6.0

6000

RD-MQA1400-1800

1400*1800

400*600

11

160

6.0

5000

RD-MQA1400-2000

1400*2000

400*600

11

160

6.5

5500

RD-MQA1400-2200

1400*2200

400*600

11

160

7.0

6000

RD-MQA1400-2400

1400*2400

400*600

11

160

7.5

6500

RD-MQA1400-2500

1400*2500

500*600

11

100

11.0

7000



Please contact us for the detail information and techniacl specification.

  • [RD-A1200-2400]Automatic lead edge feeding rotary die cutting machine[RD-A1200-2400]Automatic lead edge feeding rotary die cutting machine




FAQ



1.Q: Are you a factory or trading company?

A: We are a manufacture which is specialized in the production of various kinds

of carton equipments for 30 years.(with export license)



2.Q: Where is your factory located? How can I visit here?

A: Our factory is located in No.71-1 Huiquan Road Pujiang County,

Zhejiang  Province, China. It is about half hour from Yiwu International airport and 3 hours from Shanghai Pudong International Airport by car.

We can pick you up if you need, welcome to visit our factory.

3.Q: What are your products?

A: We are specialized in producing 3ply, 5ply, 7ply corrugated cardboard

production line, high speed printing machine, ordinary printing machine, single facer,

rotary die cutter and other corrugated cardboard production equipment.

4.Q: How does your factory do regarding quality controlling?

A: Over the years our company take “the quality first” “integrity-based”

 corporate purpose always meet users’ requirements as our sole purpose,

providing the products with excellent quality, professional technology.

To quality controlling from the very beginning to the very end .

1)All raw material we used are environmental-friendly

2)skillful workers care every details in handling the producing and packing process

3)Quality control department specially responsible for quality in each process.



5.Q: How is the evaluation of the products?

A: Products are distributed Russia, the Middle East, Africa, Southeast Asia,

EU and other countries and throughout the country. Product quality and enterprise

 reputation get the high praise at home and aboard.



6.Q: What is the payment terms?

A: T/T, it is 30% deposit due at placing order and 70% balance due before loading
