Home > Packaging & Printing > Packing Machinery > Packing Line > [RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine

[RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine

Name: [RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine
Brand: RuiDa
SKU: 116134461
Availability: InStock

[RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine thumbnail-1

[RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine thumbnail-2

[RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine photo-1

[RD-SF-380S-2000]Fingerless Type Single Facer Corrugated Machine photo-2

US$ 20,000 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles

Packaging Type:

Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Pouch

Contact Supplier Request Quote Chat Now

Pujiang Ruida Industry & Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin port for single facer corrugated machine

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles

Packaging Type Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Pouch

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Voltage 380v

Power 30KW

Place of Origin Zhejiang, China

Brand Name RuiDa

Model Number RD-SF-380S-2000

Dimension(L*W*H) 1600*3000*1800mm

Weight 5t

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Features

Fingerless type single facer corrugated machine.
Cardboard transmission is achieved by the method of vacuum suction, it equipped with high pressure air blower as well as a muffler, with adjustable of air blowing rate, to keep flute profiles stable under high speed.
All the corrugated rolls, pressure roll, gluing roll are pneumatically controlled, and the air control unit and electrical control unit are concentrated in a cabinet.
The main structure and frame are made of cast iron, up to the thickness of 200mm, equipped with independent gear box and cardan drive with submerged lubrication system to avoid noise and run stable.
The shafts of corrugated and pressure roll are all heat resisting and lubricated by lubricating grease.
The corrugated roll is made of 52CrMo precision forging alloy steel, with the treatment of hardening and tempering, grinding, laser-quenching, spraying tungsten carbide, make the hardness up to HVC1200.
Equipped with spay wetness adjusting deivce to avoid paper cracking and keep a good flute profile, it's controlled by valves.
Equipped with a lifting deivce on the heavy bridge convey to take out the corrugated roll and pressure roll for maintenance and replacement.
The pressure roll is made of medium carbon steel, with the treatment of hardening and tempering, grinding and chrome plated, the roll up and down is controlled by cylinder.
Both corrugated roll and pressure roll are equipped with pneumatic pressure deivce in order to get a stable running condition.
The gluing roll is treated with grinding, mesh snicked and chrome plated on the surface, while the doctor roll has the same treatment.
The gluing unit could be taken out integrally which is convenient for gluing roll maintenance and replacement. the gluing wall is sliding plate structure.
Electrical control glue supplying and gluing width denpends on the different size of paperboard, the glue quantity is digital displayed.
The gluing unit is available to run independently or non-independently.
The gap between gluing roll and lower corrugated roll is manual micro adjusted by turbine reducer, the parallelism is convenient adjusted by positioning screw and eccentric sleeve.
The pre-heater is made of seamless steel tube, and connected by flexible metal hose.
The machine is equipped with converter motor and Taiwan made PLC, as well as a safe defend net on the power control unit to protect the operators' safety.

Specification

General parameter
Design speed	180m/min
Design width	2000mm
Temperature scope	160-200^oC
Pressure of compressed air supply	0.4-0.9Mpa
Pressure of steam	0.8-1.3Mpa
Corrugating type	UV or UVV
Diameter of rollers
Upper corrugating roller	Φ350mm
Lower corrugating roller	Φ380mm
Pressure roller	Φ385mm
Gluing roller	Φ242mm
Doctor roller	Φ140mm
Pre-heater roller	Φ402mm
Electrical parameter of motors
Main drive motor	30KW	380V	50Hz
Air suction motor	15KW	380V	50Hz
Glue reducer motor	100W	380V	50Hz
Gluing roller gap adjusting motor	250W	380V	50Hz
Glue pump motor	2.2KW	380V	50Hz
