Automatic Roll to Roll Paper Slitter Rewinder

Specifications

Automatic Roll to Roll Paper Slitter Rewinder
2,fully automatic
3,famous component
4,CE and ISO,high quality
5.labor save

  Automatic Roll to Roll Paper Slitter Rewinder







 Specification:



Model	FQ1600C	FQ2500C
Max. width of paper roll	1600mm	2600mm
Max. base paper roll diameter	1600mm	2000mm
Min. width of base paper roll	600mm	600mm
Min. rewinding width	Not less than 40mm	Not less than 40mm
Rewinding diameter	1600mm	1600mm
Max. rewinding speed	140m/min	140m/min
Base paper	80-2200gsm depending on base paper quality
Pneumatic expanding shaft size	As per the inner diameters of customer’s paper cores
Power supply	11Kw	18Kw
Dimension	2370X2620X1030mm	4534X4509X1200mm
Total weight	3.5tons	5.5tons





Feature:



 1.        Function

   1). Hydraulic shaft-less roll stand, paper roll loading convenient and fast.

   2). Electronic hydraulic rectification, high precision.

   3). Suspend type tension system, can keep the tension invariableness.

   4). Heavy slitting component, higher quality in splitting.

   5). Frequency conversion control synchronous belt transmission, strong power, low noise.

   6). Adopt new technology, rewinding no adhesion, ensure that the distance between two paper roll is 1-2mm.

   7). The aggregate-organ research-pattern Thomas rewinding, low gravity, much more convenient to unload paper roll.



 2.        Sales terms and conditions

1)      Package: to be covered with plastic film; and totally to be loaded into one 20’fcl.

2)      Payment: 30% in advance by T/T at sight, and the balance by T/T at sight before shipment;

3)      Delivery: 45days after the receipt of the advance;

4)      Installation: to be done easily by the buyer as per the instruction manual;

5)      Warranty: one year.
