dvb-t digital signal modulator headend(ASI IN,DVB-T RF out)
ASI in and RF out
ASI DVB-T Modulator
| 4106 | DVB-T Modulator(ASI IN,DVB-T RF out) |
| 4208 | 8IN1 MPEG-2 AV DVB-T Modulator(8AV in,DVB-T out) |
| 4202 | 4IN1 H.264 HDMI DVB-T Modulator(4HDMI in,DVB-T out) |
Overview
ASI DVB-T Modulator supports all DVB-T standard channel coding and modulation parameters. It meets DVB-T and EN300744 standards, supporting FEC and RS correction and encoding.
Technical Specification
Input |
ASI |
DVB standard, BNC interface |
Modulation |
Standard |
DVB-T (EN300744) |
Transmode |
2k, 8k |
|
Bandwidth |
6M, 7M, 8M |
|
Constellation |
QPSK, 16QAM, 64QAM |
|
Protection Interval |
1/4, 1/8, 1/16, 1/32 |
|
Baudrate |
1/2, 2/3, 3/4, 5/6, 7/8 |
|
shoulder distance |
>50, (Agilent, HP 8594E) |
|
Output |
Interface |
RF, F-head |
Impedance |
75Ω |
|
Level Attenuation |
-26dbm~+3dbm (0.1db step) |
|
Frequency |
30~960MHz, 1khz step |
|
MER |
≥ 42db |
|
Control |
IP remote |
NMS (Ethernet Port, RJ-45), 10/100m base-TX, |
Front panel |
Keyboard + LCD |
|
General Features |
Size |
482mm×280mm×44mm |
Temperature |
0~45°C (Operation); -20~80°C (Storage) |
|
Power |
100-240VAC, 50Hz, 25W |
Order Guide
4106 |
ASI in, DVB-T RF out |
4208 |
8×AV in, DVB-T RF out |
Network Management Software
Modulator setting:
NIT edit(support LCN):
Developing :
Assembling :
Packing:
Stocking:
Company information:
Certificate&Exhibition:
