All Kinds of Single and Double Colors LED Screen Control Card

US$ 35 - 60 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Model Number:

BX-5M3

Usage:

Other, indoor/semi-outdoor

Shenzhen Xuancai Optoelectronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Model Number BX-5M3

Usage Other, indoor/semi-outdoor

Tube Chip Color Other, single/double colour

Display Function Animation

Screen Dimension Single color128K Dual color 64K

Technical parameters:

Product model	BX-5M3
Control area	Single color128K:320016 320032 272048 204864 163280 134496 1152112 1024128 Dual color64K:320016 204832 136048 102464 81680 67296 576112 512128
Storage capacity	2MByte
Screen types	All kinds of single and double colors LED screen
Software function	Screens cluster management/multi-program/multi-areas display/multi-languages
Program type	Normal/Shared program
Program quantity	Support 128 programs,24 areas for each program
Area type	Image/text/animation/lunar calendar/digital clock/analogue clock/timer/temperature/ temperature & humidity
Frame mode	Most advanced colorful / magic graphics frame/Area frame
Background	Support text/image/colorful and active background
Time mode	Analogue clock/digital clock/timing and counting-down timer (support multi-groups)
Communication mode	100M Ethernet and USB port
Interface	1 nos 50 PIN/128 lines
Sensors supported	Temperature /humidity
Remote control	Remote control program/lock screen/brightness adjustment/power on/off /screen test
Bright regulation	16 grades brightness, manual and auto-timing adjustment/remote control
Power on/off mode	Auto-timing powered on/off /software power on & off/remote power on&off
Voltage	5V (3.5V~6.5VwideVoltage)
Maximum power	≤2W
Temperature	-40°C~80°C
Secondary developments	Provide the DLL and corresponding demos
Software	LedshowTW2015
User manual	LEDshowTW software user manual
Adapter	HUB256-T8 HUB128-T8 HUB256-T12 HUB128-T12
