Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
key-tek
Model Number:
K-TEK-A68KP-BL
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name key-tek
Model Number K-TEK-A68KP-BL
Application Other, ticket vending machines, gas stations, cash machines (ATMs), Kiosks
Keypad Button Material Other, stainless steel





  12 keys waterproof backlight keypad with rear panel mounting



Quick Details:



1. 12 Keys Vandal proof IP65 Stainless Steel keypad



2. carbon-on-gold key switch technology



3. Top panel mounting



4. CE, FCC, RoHS, IP65, ESD



Descriptions:



1. 12 keys IP65 dynamic compact format vandal proof Stainless Steel industrial numeric keypad



2. with industrial PCB electronics controller shieded & protected by stainless steel housing



3. industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without any noise



4. ,top stainless steel plate with sealing gasket for easy & tight sealing and mounting to enclosure or panel



5. threaded bolts under top stainless steel plate for top panel mounting solution.



Special Features:



1. Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.



2. key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off. Or protrusive engraving available.



3. With carbon-on-gold key contact with long stroke 2.0mm, with unique double over-travel protection.



4. Waterproof/dirt-proof execution according to degree of protection IP65, waterproof and dirt proof encapsulation with unique membrane.



5. Easily mounting into enclosure or panel, and is provided with PS/2, or USB, RS232, connection output cables that plug directly into the host computer for normal keypad operations.



6. OS: All windows, Linux, Unix, Mac OSX



Applications:



This industrial keypad is mainly targeted for use for:



A: unsupervised or semi -supervised positions of varied access applications,



B: internet terminals and information kiosks at universities,



C: shopping malls, hotels, airports, railway stations and other public areas,



D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.



Specifications:

COMMUNICATION PARAMETER:

Standard USB, PS2

12 actuator

 0, 1, 2, 3, 4, 5, 6, 7, 8, 9,*, #. 3 x 4 scanning code

Any customized layout/codes are available upon customers’ requirements

RS232 interface

Communication velocity

9600bps.

Data format

N, 8, 1.

12 actuators:

 0, 1, 2, 3, 4, 5, 6, 7, 8, 9,*, #. 3 x 4 scanning code, 3 x 4 scanning code.

Any customized layout/codes are available upon customers’ requirements



MECHANICAL DATA

Switching material

Carbon-on-Gold

Actuation Force

0.6N +/-0.1N (pressure point).

Key travel

2.0mm

Lettering

laser engraving, or raised letters

Front pane

brushed stainless steel

Actuator/keys materials

stainless steel.

Dimensions

88.0mm x 102.0mm.

G.W.

0.60KGs



ELECTRICAL DATA

Power supply voltage

 5V DC

Power Consumption

Under 300mW for operation, under 200mW for non-operation.

Electrical lifetime

> 5 years

EMC Standard

 It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004

Communication interface

 PS2, USB or RS232 are all available.



ENVIRONMENTAL ADAPTABILITY

Operating temperature

-20oC to +60oC

Storage temperature

-30oC to +70oC

Operating RH

30-90%

Atmospheric pressure

60-106Kpa



RELIABILITY

Certification

RoHS Compliant, CE and FCC,ESD.

Protection Level

IP65(front panel)

Vandal resistant

IK09

Key Lifespan

>10 million actuations

MTBF

>50000H

MTTR

<30min



Warranty

12 keys metal keypad access control with rear panel mounting

KEY-TEK guarantee our products and workmanship up to a full year!

shipment

12 keys metal keypad access control with rear panel mounting

Certifications

All of our products have CE, ROHS, FCC, IP65, IP68 and Patents!

12 keys metal keypad access control with rear panel mounting

Fatory Show

12 keys metal keypad access control with rear panel mounting
