Help CenterSealed Shield Easy Cleaning Keyboard With Ruggized Touchpad
Related Products
-
All-in-one Panel Mount Industrial Membrane Trackball KeyboardNegotiableMOQ: 1 Piece -
Industrial Membrane Beverage Keyboard With Optical TrackballNegotiableMOQ: 1 Piece
-
2016 New OEM Oil Resistance Easy Clean Industrial Membrane KeyboardUS$ 99 - 159MOQ: 1 Piece
-
IP68 Industrial Custom Layout Membrane Keyboard for Food and BeverageNegotiableMOQ: 1 Piece
-
IP65 Rated Industrial Desktop All-in-one Membrane Keyboard Wtih TouchpadNegotiableMOQ: 1 Piece
Quick Details: 1. IP65 dynamic scratch proof industrial membrane keyboard with full keyboard functionalities. 2. Clean key for easy cleaning via lock/disable the entire keyboard without needing to take the keyboard from PC 3. Durable and anti-microbial keyboard surface
Descriptions: 1. 108 keys IP65 rated compact format industrial membrane keyboard with full keyboard functionalities 2. With with sealed & ruggedized tough touchpad, integrated numeric keypad & function keys 3. Foil-covered aluminum front plate is mounted flush with durable polyester withstand to most chemicals and liquids under the harshest environments 4. With gold-on-gold metal dome key switch technology with short stroke 0.45mm with tactile feeling 5. With anti-microbial keyboard surface, 6. Clean key for easy cleaning without needing to take out the keyboard from PC 7. Top panel mounted.
Special Features: 1. Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality 2. The foil-covered aluminum front plate is mounted flush for easy cleaning. 3. The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt,grease and corrosive liquids to NEMA 4X, which means it can withstand directed hose water, disinfectants, environmental contaminants and heavy industrial use. 4. PS/2, USB connection cables that plug directly into computer like keyboard operations. 5. Ease of customizing with multiple languages, to accommodate foreign or custom variants. 6. This stylish, rugged medical keyboard is ideal for any application requiring a rugged enclosure and low profile. 7. Clean key -Prevents data from being sent while the keyboard is wiped down, allowing user to clean at any interval with minimal downtime
Applications: This keyboard is ideal for use in environments ranging from manufacturing to material handling to medical settings. Its numeric pad allows for easy data entry. A: MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc; B: MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc C: MILITARY: Army, Navy, Air force D: INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing environments, warehouses etc E: OTHER INDUSTRIES
Specifications:
MECHANICAL DATA | |
Key |
108 |
Key switch Technology |
metal dome PCB with gold-on-gold metal dome key switch technology with short stroke keys |
Actuation Force: |
1.0N for key 13.0mm x 13.0mm (press point) |
Key travel |
0.45mm |
Key switch Lifetime |
3 mil. operations |
Protection Level |
IP65, NEMA 4x |
Mounting Type |
Top panel mounting or Desk Top. |
Operating Temperature |
-20 °C to +50 °C |
Colors |
4 (Blue, White, Grey, Black) |
G.W. |
1.30KGs |
Key Dimensions (print area) |
13.0mm x 13.0mm |
Dimensions |
410.0mm x 160.0mm (Front Panel) |
TOUCHPAD | |
Touchpad cover |
Composite |
Motion Detection | |
Method |
capacitive |
Resolution |
40 counts / mm |
More than Lifetime 10 million strokes | |
Mutual Capacitance sensing | |
X/Y position sensing resolution |
40 counts/mm |
X/Y position reporting |
Relative |
Output (self-detectable depending on cable) |
PS2 or USB |
Tracking speed |
Maximum 1,016 m/sec |
Power supply voltage |
5 V DC ±0.25V |
Current rating (active mode) |
17 mA |
ELECTRICAL DATA | |
Supply Voltage |
+5V DC +/-5% |
Current Rating |
appr. 30mA |
|
EMC Standard: |
It is compliance with the council IEC 61000-4-2:2008; IEC 61000-4-3:2006+AI:2007+A2:2010; IEC 61000-4-4:2004 |
EMI: |
EN 55022: 2010 |
EMS: |
EN 55024:2010 |
Lifespan |
> 3 years |
Interface: |
PS2, USB available. |
OS: |
All windows, Linux, Unit, Mac OSX |
RELIABILITY | |
Certification |
RoHS Compliant, CE and FCC,IP65,ESD |
Protection Level |
IP65(front panel) |
Key Lifespan |
>3 million actuations |
MTBF |
>50000H |
MTTR |
<30min |
