IP65 Rated Industrial Desktop All-in-one Membrane Keyboard Wtih Touchpad

IP65 Rated Industrial Desktop All-in-one Membrane Keyboard Wtih Touchpad thumbnail-1
IP65 Rated Industrial Desktop All-in-one Membrane Keyboard Wtih Touchpad thumbnail-2
IP65 Rated Industrial Desktop All-in-one Membrane Keyboard Wtih Touchpad photo-1
IP65 Rated Industrial Desktop All-in-one Membrane Keyboard Wtih Touchpad photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Type:
Wired
Contact Supplier Request Quote Chat Now
Key Technology (China) Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Desktop
Type Wired
Style Standard
Interface Type PS/2, USB
Brand Name IKB-MKB
Model Number K-TEK-D275TP-FN-DT
Place of Origin Guangdong, China

Model NO:K-TEK-D275TP-FN-DT

Dimension:304.40mm x 195.8mm x 47.3(22.3) mm



Description:88 keys IP65 dynamic rated compact format industrial membrane keyboard with integrated numeric keypad and function keys on the upper line, IP65 dynamic sealed and ruggedized tough touchpad for fast and accurate cursor position, 2.0mm thickness industrial metal dome PCB with gold-on-gold metal dome key switch technology with short stroke 0.45mm with extremely tactile feeling for reliable data input, with Clean key for easy cleaning via lock/disable the entire keyboard without needing to take the keyboard from PC, surface mounted extremely flush with anti-microbial, durable and scratch-proof polyester withstand to most chemicals and liquids under the harshest environments, ruggedized and backed with 3.0mm alumium plate with sand blasting & oxygenation treatment , mountable desk top version with robust polycarbonate case.



APPLICATIONS:
This keyboard is ideal for use in environments ranging from manufacturing to material handling to medical settings. Its key pad allows for easy data entry.
MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc MILITARY: Army, Navy, Air force
INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing environments, warehouses etc
OTHER INDUSTRIES

MAIN FEATURES:
Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionalityThe foil-covered aluminum front plate is mounted flush for easy cleaning.
The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt, grease and corrosive liquids to NEMA 4X, which means it can withstand directed hose water, disinfectants, environmental contaminants and heavy industrial use.
PS/2, USB connection cables that plug directly into computer like keyboard operations.
Ease of customizing with multiple languages, to accommodate foreign or custom variants. This stylish, rugged medical keyboard is ideal for any application requiring a rugged enclosure and low profile.
Clean key
-Prevents data from being sent while the keyboard is wiped down, allowing user to clean at any interval with minimal downtime.

MECHANICAL DATA:
Number of Keys: 89
Key switch Technology: metal dome key switch technology with short travel keys
Actuation Force: 1.0N for key 13.0mm x 13.0mm (press point)
Key Travel: 0.45mm
Key switch Lifetime: 3 mil. operations
Protection Level: IP68, NEMA 4x
Mounting Type: stand alone mounting desk top .
Operating Temperature: -20 °C to +50 °C;
Colors: 4 (Blue, white, grey, black)
G.W.: 1.00KGs
Key Dimensions (print area): 13.0mm x 13.0mm
Dimensions: 304.4.0mm x 195.8mm x 47.3(22.3) mm (L x W x H)

TOUCHPAD:
Touchpad cover: Composite
Motion Detection
Method: capacitive
Resolution: 40 counts / mm
More than Lifetime 10 million strokes
Mutual Capacitance sensing
X/Y position sensing resolution: 40 counts/mm
X/Y position reporting: Relative
Output (self-detectable depending on cable): PS2 or USB
Tracking speed: Maximum 1,016 m/sec
Power supply voltage: 5 V DC ±0.25V
Current rating (active mode): 17 mA

ELECTRICAL DATA:
Supply Voltage: +5V DC +/- 5%
Current Rating: appr. 30mA
EMC Standard: It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004 EMI: EN 55022: 2010 EMS: EN 55024:2010
Lifespan > 3 years
Interface: PS2, USB available.
OS: All windows, Linux, Unit, Mac OSX

RELIABILITY
RoHS , CE, FCC, ESD
Protection Level: IP68
Key Lifespan >3 million actuations
Touchpad lifespan > 10 million of times
MTBF >50000H
MTTR <30min

IP65 rated industrial desktop all-in-one membrane keyboard wtih touchpadIP65 rated industrial desktop all-in-one membrane keyboard wtih touchpad
