IP65 Industrial Rugged Easy Cleaned Membrane Keyboard With Integrated Keypad
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Other, DESKTOP
Type:
Other, WIRED
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen Zhen and HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Proof Membrane Medical Keyboards With Laser TrackballNegotiableMOQ: 1 Set -
Top Panel Mount Industrial Membrane Keyboard With Optical TrackballNegotiableMOQ: 1 Set
-
Scratch Proof Industrial Membrane Keyboard With Trackball for BeverageNegotiableMOQ: 1 Set
-
IP65 Industrial Membrane Hygienic Keyboard With Sealed Touch Pad MouseNegotiableMOQ: 1 Set
-
IP65 Industrial Hygienic Membrane Keyboard With Optical TrackballNegotiableMOQ: 1 Set
Products Status
Stock
Application
Other, DESKTOP
Type
Other, WIRED
Style
Standard, Other, Standard, STANDARD
Interface Type
PS/2, USB, Other, PS/2, USB, USB PS2
Brand Name
HI-KEY KEY-TEK
Model Number
K-TEK-D410KP-FN
Place of Origin
Guangdong, China
Description: 108 keys IP65 compact front panel mounting medical keyboard, metal dome key switch technology with short stroke 0.45mm.
Dimension: 410.0mm x 160.0mm (Front Panel)
MAIN FEATURE:
- The foil-covered aluminum front plate is mounted flush for easy cleaning. The polyester front foil is wear-and tear-resistant and can withstand most chemicals and liquids. The keyboard is protected against dust, dirt, grease and liquids to IP65/NEMA4 and is available in PS/2 and USB versions. Custom keyboard layouts or imprints are available upon request.
- This keyboard is available in different keyboard layouts. This stylish, yet rugged medical keyboard is ideal for any application requiring a rugged enclosure and low profile.
SPECIFICATION KEYBOARD:
- Number of Keys: 108
- Key switch Technology: metal dome key switch technology with short travel keys
- Actuation Force: 1.0N for key 14.0mm x 14.0mm (press point)
- Key Travel: 0.45mm
- Key switch Lifetime: 3 mil. operations
- Protection Level: IP65, NEMA 4x
- Mounting Type: Top panel mounting or Desk Top.
- Operating Temperature: -20 °C to +50 °C;
- Colors: 4 (Blue, white, grey, black)
- G.W.: 1.4KGs
- Key Dimensions (print area): 14.0mm x 14.0mm
- Dimensions: 410.0mm x 160.0mm (top panel)
ELECTRICAL DATA:
- Supply Voltage: +5V DC +/- 5%
- Current Rating: appr. 20mA
-
EMC Standard: It is compliance with the council EMC directive 89/336/EEC
EN55022: 1988+A1: 2000+A2: 2003
EN55024: 1988+A1: 2001+A2: 2003 - Emission EN 50081-1
- Immunity: EN 50082-1
- Lifespan > 5 years
- Interface: PS2, USB available.
- OS: DOS/Window95/98/NT/ME/2000/2003/XP/Vista, Linux, Unit, Mac OSX
RELIABILITY
- RoHS Compliant, CE and FCC
- Protection Level: IP65 (front panel)
- Key Lifespan >3 million actuations
- MTBF >50000H
- MTTR <30min
