Parameters
| 50KW DIESEL GENERATOR DETAILS | |||
| Model | HQBL50GF | Start Method | DC 24 |
| Generator Prime Power(KW/KVA) | 50/63 | Output Current(A) | 90 |
| Standby Power(KW/KVA) | 55/69 | Voltage(V) | 400/230 |
| Power Factor | 0.8 | Phase | Three phase, Four Wires |
| Frequency(Hz) | 50 | Weight(kg) | 850 |
| Size(mm) | L | W | G |
| 1800 | 700 | 1600 | |
| Diesel Engine Data | |||
| Manufacturer | Ricardo Engine | Model | R4105ZD |
| Rated Speed(Rpm) | 1500 | Diesel Engine Max Power(KW/H) | 56 |
| Cylinder No. | 4 | Arrangement Type | In-line |
| Bore×Stroke(mm) | 105×115 | Displacement(L) | 4.33 |
| Intake Method | Turbocharged | Compression ratio | 17.0:1 |
| Fuel | Diesel Fuel | Full Load Consumption(g/kw.h) | ≤228 |
| Oil Capacity(L) | 13 | Start Method | Electrical |
| Engine Cooled Method | Radiator Max 40℃,fans are driven by belt with safety guard. | ||
| Alternator Data | |||
| Manufacturer | China Stanford | Model | XN50 |
| Rated Power(KW/KVA) | 50/63 | Excitation Type | Brushless |
| Insulation Class | H | Protection Grade | IP22 |
| Unload Voltage Adjustment | ≥±5% | Stable Voltage Adjustment | ±1% |
| Efficiency (%) | 94.8 | Voltage Control Method | AVR |
Huaquan Power Company professional producing diesel generators, natural gas generators,water pump units,light towers,diesel engines, and spare parts,we offer the variety models generator adopt the famous brand engine like cummins,ricardo,deutz,perkins,isuzu,steyr,weichai,yuchai etc , alternators we adopt the top brand like stamford, marathon,faraday etc.Our generators including silent generators, open generators, ats generators, trailer generators etc.Reliable quality and competitive prices let us get good feedback from our clients.
1.Package:All generators standard package by Plywood package, free fumigation type.Make the generator more safe during the transportation time.
2.Shipping: All generators will delivery by ship.We accept the FOB OR CIF item. Professional shipping company service provided beause our More years experience.Competitive price and High efficiency for the whole delivery time.
3.Delivery:For norma genset, after the deposit within 2-5 days we will start delivery.For special requirements type generators, only need wthin 10 days to finish.
1.Make the professional power plan project idea for our client depends on the years experience.
2.Maintenance generators or engines /alternators.
3.Supply diesel generators,natural gas generators,gasonline generators, light towers,diesel engines, alternators,or spare parts.
4.Free technical support all the time.
5.Fix generators,engines, alternators etc.
6.Offer power from 5kva to 1500kva with variety models.
1.Huaquan Power offer complete lines generator after sale service. We offer 1 year or 1000 hours runing time for warranty.
2.We offer technical support for free all the time.
3.We offer the spare parts for our generators all the time,any time you can contact us for spare parts.
