Home > Products > ~50kva Generators > Weichai Huaquan OEM 50kva Weichai Generator Electric

Weichai Huaquan OEM 50kva Weichai Generator Electric

Name: Weichai Huaquan OEM 50kva Weichai Generator Electric
Brand: huaquan
Availability: InStock

FOB Price

US$ 3,000 - 6,500 / Set

1 Set(Min. Order)

Port Qingdao Port Of China
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	huaquan
Model Number	HQ50GF	Output Type	AC Three Phase
Speed	1500/1800	Frequency	50/60HZ
Rated Power	50kva	Rated Voltage	230/400
Rated Current	90A

Product Description

weichai huaquan OEM 50kva weichai Generator Electric

Product Description

50kva Generator Diesel Standard Configurations
1	Standard High-level quality engine Ricardo series
2	Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H.
3	No-maintenance start battery
4	After acidification under frame, High-level strong
5	Electric start, use key start
6	Standard control panel Spray-print or LCD show panel
7	Daily fuel tank
8	High-level shock absorber system
9	Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler
10	40°C radiator as standard
11	Exhaust silencer
12	Charger motor for battery.
13	Standard export box
14	Manuals
15	Tools box

Product Picture Show

Product Details

Genset model	HQ
Type	open/sound proof/weather proof
Genset output power range	20kva-300kva
Rated voltage	220/380V,230/400V,240/415V,120/240V
Frequency	50/60HZ
Power factor	0.8
Rated speed	1500/1800rpm
Output type	AC three phase/single phase
Motor	brushless
Frequency	<3%
Frequency at stable state:	<0.5%
Frequency deviation at instantaneous state	≤+10%
Frequency return time	≤3s
Voltage deviation at stable state	≤±1%
Voltage deviation at instantaneous state	≤+20%
Voltage return time	≤4s
Voltage modulation	≤0.3%

The specification of ricardo engine:

Model	495(Z)D, R4105(Z)D, R6105(Z)(AZL)D, 6113D,6126ZLD
Cooling Method	water cooled
Rotating speed	1500/1800rpm
Governor system	electrical or mechanical governor
Aspiration mode	natural aspirated or turbocharged
Starting method	12/24V DC electric starting
Stroke	4 stroke

The specification of alternator:

Brand	Stamford, Leroy semor, Maraton and chinese alternator etc.
Regulator	AVR automatic voltage regulating
Excite type	pret or shunt
Connecting type	3PH star, 3PH-DELTA
Steady frequency change	0-5%
No load voltage	≥95%-105
Steady voltage	≤±1
Insulation degree	H degree
Exclosure degree	IP23

Production Flow with Packaging & Shipping

Our Services

Huaquan provides a full line of brand new and high quality products.Each and every unit is strictly factory tested Warranty is according to our standard conditions:12 months or 1000 running hour’s ,subject to the earlier one .Service and parts are available from our factory.

Company Information

Weifang Huaquan Power Machinery Co.,Ltd, located in famous city ---Weifang.Huaquan Company professional producing Diesel Generators,Engine Generators,Alternators Generators and Offer All spare parts.The power range we offer from 5kva~1000kva.

We copperate with the famous engine company like Ricardo,Cummins.Perkins,Volvo,Deutz,Steyr,Isuzu,Shangchai,Yuchai,Changchai etc.

Our Export Experience

We specialized in producing diesel generators. We have exported to many countries and widely used in domestic.

1. Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.

2. Domestic: Send to most of the cities in china, and get high praise from our clients.

FAQ

1.What's your power range of Generators?

Answer: We can offer the range from 10kva~1000kva.

2.What's your delivery time?

Answer: Generally,we can delivery in 7 days after we get the deposit.

3.What's your payment?

Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before shipping.

4.What's your warranty?

Answer: All our products we offer on year warranty.

5.What's your MOQ?

Answer:We accept the MOQ is 1 set.
