Help CenterMilk Drink Can Filling Machine
Related Products
Specifications
Rated capacity : 9000CPH (250ml)Way of filling : gravity filling
Suitable can diameter: 53-66mm, height 70-175mm
General Description
Aluminum/Tin Can filling & sealing machine, it is the integrated filling and sealing equipment for tear-off tin, designed and manufactured on the basis of introducing and digesting and absorbing the filling technology form Switzerland. Its RYGF machines in series are suitable for filling and sealing the mineral water, juice and milk drinks etc...
Technical parameters
Model RYGF18-4
Working positions filler 18, capper 4
Chain distance: 114.3mm
Rated capacity : 9000CPH (250ml)
Way of filling : gravity filling
Suitable can diameter: 53-66mm, height 70-175mm
Filling pressure: 0.25-0.35Mpa
Filling temperature: 0-92° C
Filling diameter: 972mm
Compressed air consumption: 0.5Nm 3 h (0.4-0.5MPa)
Rating voltage: 380V, 50Hz
Installed power : 3KW
Dimension : 3150× 1730× 2700mm(L× H× W)
Height of conveyor: 1200mm
Machine weight : 3500 Kg
Main composition
1) Main motor: ABB
2) Sliding bearing: Igus (Germany)
3) Seals: Busak+Shamban (U. S. A)
4) Pneumatic components: FESTO (Germany)
5) PLC: MITSUBISHI (Japan)
6) Touch screen: PRO-FACE (Japan)
7) Frequency inverter: MITSUBISHI (Japan)
| Item | Industry standard | Index | |
| 1 | Filling accuracy | ±2.5mm | ±2mm |
| 2 | Filling qualified rate | ≥85% | ≥93% |
| 3 | fluid loss rate | ≤1% | ≤0.8% |
| 4 | Can loss rate | ≤1% | ≤0.8% |
| 5 | Cover loss rate | ≤1.2% | ≤1% |
| 6 | Sealing qualified rate | ≥99% | ≥99.5% |
