SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine

SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine photo-1
SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine photo-2
SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine photo-3
SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine photo-4
SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine photo-5
SF1092 Type 5TPD Good Quatlity Kraft Paper Making Machine photo-6
US$ 110,000 - 1,000,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, kraft paper making machine
Processing Type:
Other, kraft paper making machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or other main ports
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, kraft paper making machine
Processing Type Other, kraft paper making machine
Place of Origin Henan, China
Brand Name shunfu
Model Number SF1092
Voltage 380v
Power(W) 100-150kw
Dimension(L*W*H) Depends on model and configuration
Weight 10-13tons
Certification Other, ISO9001
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

                            Kraft paper making machine with good quality

Product Description

Technical data

Raw material: waste paper, recycled paper

Output paper: corrugated paper, kraft paper, carton paper

Net width: 1092-1200 mm

Output weight: 100-250g/m2

Capacity:  3-5T/D

Working speed: 80-120m/min

Rail gauge: 1800mm

Drives : AC frequency conversion speed regulator . Processing transmission.



Main frame of the kraft paper line

Name

Equipment

Specification

Qty(set/s)

Mesh cylinder

part

             cylinder mould

φ1250mm×1450mmmm

2

couch roll

φ400mm×1450mm

2

               Reverse roll

φ400mm×1450mm

1

Shore hardness is 38o±2, mechanical loaded equipment .

Dryer part

dryer can

φ 1500mm×1450mm

2

touch roll

φ 400mm×1450mm

1

Shore hardness is 90o±2, pneumatic loaded.

Reverse pressing roll

φ 350mm×1450mm

1

Shore hardness is 90o±2, mechanical loaded.

   Press part

top marble roll

φ 400mm×1450mm

1



bottom marble roll

φ 400mm×1450mm

1

Pneumatic loaded device.

  Structure of frame



Trough type, its material is cast iron.





Pulp machine

SF1092 type 5TPD Good Quatlity Kraft paper making machine



Paper making machine

SF1092 type 5TPD Good Quatlity Kraft paper making machine



CE  certificate

Packaging & Shipping

  SF1092 type 5TPD Good Quatlity Kraft paper making machine

Our Services

What we can provide:

1.787,1092,1575,1760,1880,2400,2640,2800,3200mm paper making machine

2.paper egg tray machine

3.pulp making equipments

4.paper making equipments

5.paper processing equipments

6.all kinds of spare parts

Best Service:

1.We will provide you all technical consultation and make the drawing and proposal for you.

2.We will send technicians to install and test the machine for you.

3.We will train skilled workers for you.

4.We will supply best pre-sale, after-sales service for you.

Company Information

Henan Province Qinyang Shunfu Paper Making Machinery Co; Ltd. was founded in 1988

We are specialized in the production paper making machinery, pulping equipment, paper egg

tray making machine and paper processing equipment. Our products had been certificated by

ISO9001 and exported to many countries, such as Uzbekistan, Russia, Kyrgyzstan, Nigeria,

Ukraine, Botswana, Libya, Algeria, El Salvador, Lebanon, Moldova, Bolivia.



Our workshop and customers
