Specifications
30db shark fin antenna GPS and GSM combination antennaAll the material we use the best
We deal with factory, can give you bes
Multi function shark fin antenna
3-5V,28dBi gain,SMA male connector,magnetic mounting
Part number:GKA-GPS-SMAZ5
GPS antenna:
One. Dielectric antenna specification
1. GAS1575R(25*25*4mm)
2. Center frequency 1575.42mhz+/-2 MHZ
3. V. S. W. R 1.5:1
4. Band width +/-5 MHZ
5. Attenuation fo+/-100mhz>30db
6. Impendence 50 ohm
7. Peak gain >3dbic based on 7*7cm ground plane
8. Gain coverage >-4dbic at -90<0<+90(over 75% volume)
9. Polarization rhcp
GSM antenna
Frequency:890-960&1720-1920
Gain:2
V.S.W.R:2.0
Polarization:Linearization
Impedance:50
Cable:RG-174
Connector:Fakra(if you need, we can change to SMA/SMB/SMC/BNC/MCX/MMCX/and others)
Operating Temperature:-40~+85
Two. Lna specification
1. Lna gain(without cable) 28db typical
2. Noise figure 1.5db
3. V. S. W. R <2.0
4. Dc voltage:2.7-5.0v+/-0.5v
6. Dc current 12mA max
Three. Mechanical specification
1. Weight <70gram
2. Size .49*39*14mm
3. Cable rg174/u 3m or 5m cable
4. Connector :MMCX male ect.
5. Mounting base: Magnitec
6. Housing black
Four. Lna
Two poles LNA.
Five. Environmental specification
1. Working temp -40~+85
2. Storage temp -40~+100
3. Vibration sine sweep 1g(0-p)10~50~10hz each axis
4. Humidity 95%~100%rh
5. Weatherproof :100%
6. Mtbf=1*10-6/pc. Hr 40+/-5 dc=5.0v+/-0.5v 2000pcs for 480
