The application advantages of the electromagnetic pump
1.Improve the metal recovery Electromagnetic pump system plays an important supporting role on improving the metal recovery of electromagnetic pump system, through the fast contact and rapid melting cycle, reduce sunk shorten melting process produce the scum of the recovery rate increase. Improve recycling the melting pot of the yield, improve the furnace cycle, and improve the production efficiency.
2. Convenient to add alloy composition
| Alloy additive |
Usingthe electromagnetic pump melt rate |
Directlythrough the melting potmelt rate |
| Silicon briquette | 97% | 94% |
| Magnesium pounds(10kg/piece) | 98% | 90% |
| Manganese piece | 98% | 94% |
| Iron spatter content (iron slag) | 98% | 90%(powder,tablet) |
| Copper | 99%(scraps) | Only flake |
3.beneficial to uniform chemical composition
| Alloy additive |
Every tons of material usuality the dissolution of the time |
| Silicon | 10-15 minutes |
| Magnesium pounds(10kg) | 10 miutes |
| Manganese nodule | 8-10 miutes |
| Briquette | 10-15 minutes |
| Copper | 15 miutes |
4. Oxide residue reduceRely on the circulation of the powerful electromagnetic pump function and heat transfer ability, can reduce the surface temperature of molten pool, under the molten pool temperature can be controlled within 4 degrees. Through the material of high speed whirlpool flow in well, solid waste pile sinking fast to dissolve the bottom, reduce the contact with air time, shorten the melting time, the effective measures to greatly reduce the oxidation of slag formation.
5. Save energyElectromagnetic pump system of the operating characteristics unique to reduce energy consumption, reflected in the following respects:
Aluminum pool to the heat efficiency greatly improved, by electromagnetic pump system to create high speed large flow acceleration of the heat transfer, and produced a strong form vortex of sinking ability.
The molten pool temperature gradient (poor) is less than 4 degrees.
Through the door of the heat loss reduced, although have had to open the door into alloy.
Through practical application of energy saving at least 10-20%
6. Environmental characteristicsElectromagnetic pump systems rely on its unique design has caused many environmental advantage. Outside the furnace control characteristic is good, when the door closed allow many types of waste and other additives to aluminum molten pool. Alloy additive (including pure and composite alloy), melting and charging can in the furnace door close completed. This has very obvious advantage is the least furnace smoke from the flue open sending out. At the same time keep furnace temperature and open door into the furnace when the amount of air minimization.
7. Shorten melting time improve production efficiencyRely on very high speed and capacity of flow ability, electromagnetic pump system can improve the rate of melting pot of fuses.
8. Scrap is flexible and convenientRely on the eddy current electromagnetic pump produce all kinds of waste to melt.
9. Help the uniformity of the melt temperatureBy electromagnetic pump system to produce a rapid cycle role, in the pool is 1 m high places will be less than 4 °C temperature.
Electromagnetic pump operating characteristics
♦ No physical components connection
♦ No contact with melting liquid
♦ No moving parts
♦ Extremely reliable sealing
♦ Can work continuously
♦ The velocity is easy to control,
♦ Easy operation
♦ Structure is convenient for installation
♦ Low power consumption
♦ Realizes remote operation
