Automatic Milling Machine

Name: Automatic Milling Machine
Brand: Mooge
SKU: 115869879

US$ 8,000 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Surface Grinding Machine

CNC or Not:

Normal

Zhangjiagang Mooge Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Surface Grinding Machine

CNC or Not Normal

Max. Grinding Diameter 120mm

Max. Grinding Length 1000mm

Place of Origin Jiangsu, China

Brand Name Mooge

Model Number MG series

Voltage According to your demand

Power(W) 1100 W

Dimension(L*W*H) 1550*1060*1590

Weight 750KG

Certification CE/ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

automatic blade sharpener
1. Vertical & horizontal spindle;
2. Automatic;
3. X, Y auto. feed;
4. Z auto. up

Automatic blade sharpener , Automatic blade sharpening machine

Product Description

Feature :

1,Z-automatic feed sharpenning head

2.rectangular guideway on lifting platform

3.high stability

4.hardened on X ,Y,Z axies

Technical parameters

Model	Unit	MG-500
Table Size(L×W)	mm	460x180
Max. table travel	mm	500x190
Max. workpiece to be ground	mm	500x190
Max. distance of table to spindle center	mm	335
Table slide-way		V-type rail with steel ball
Cross feed on handwheel per revolution	mm	2.5
per graduation	mm	0.02
Vertical feed on handwheel per revolution	mm	1.25
per graduation	mm	0.01
Wheel speed	r.p.m	2850
Wheel size(dia.×width×bore )	mm	200×16×31.75
Spindle motor	w	1100
Coolant pump	w	40
Net weight	kg	650
Gross weight	kg	750
Overall dimension(L×W×H)	m	1.55x1.06x1.59
Packing size(L×W×H)	m	1.06x1.17x1.87
