Specifications
pipe crusher1.applied for crushing plastic material pipe
2.easy to operate
3.high cost performance
pipe crusher , Strong plastic pipe crusher
Features:
1) Specialized blades for crushing pipes (PP-R, PE, PVC)
2) Steel body and clamping blade prevent the machine from cracking
3) Stepped blades increase shearing strength and crushing efficiency
4) Movable screen is easily to assembly, disassemble and wash
5) Sound separation layer in the feeding door lowers operations noise levels
Plastic pipe crushing machine/plastic pipe crusher/pipe crusher
SWP Series Horizontal PVC pipe crushing machine is mainly used for breaking relatively long PVC special shaped material,
such as plastic door & window, plastic pipe, sheet, etc. there is no need to cut. Once continuous feeding can be conducted.
Internal design of SWP Series Horizontal Plastic Breaking Machine is rather distinct.
Main Technical Parameters:
Model |
SWP300 |
SWP400 |
SWP500 |
SWP600 |
SWP500A |
SWP500B |
SWP600A |
SWP600B |
|||
Rotary Knife Diameter(mm) |
400 |
400 |
400 |
400 |
400 |
600 |
400 |
600 |
|||
Rotary Knife Quantity (unit) |
3 |
5 |
5 |
10units /2groups |
6units /2groups |
6units /2groups |
6units /2groups |
6units /2groups |
|||
Rotary Knife rpm(r/min) |
600 |
500 |
500 |
480 |
500 |
480 |
480 |
480 |
|||
Static Knife Quantity(unit) |
2 |
2 |
2 |
2x2 |
2 |
2units |
4units /2groups |
4units /2groups |
|||
Sieve Aperture(mm) |
φ10 |
φ12 |
φ12 |
φ12orφ14 |
φ10 |
φ12 |
φ14 |
φ14 |
|||
Crushing Capacity(kg/h) |
150-200 |
300-400 |
400-500 |
500-700 |
250-350 |
300-450 |
350-500 |
400-650 |
|||
Power(kw) |
13.2 |
18 |
18-22 |
33 |
25 |
25-30 |
33-40 |
33-40 |
|||
Feed Door Caliber(mm |
300x200 |
350x300 |
500x300 |
650x300 |
500x280 |
500x350 |
650x280 |
650x350 |
|||
Weight(kg) |
950 |
1300 |
1500 |
1800 |
1600 |
1800 |
2250 |
2800 |
|||
