super electrochemical long life fresh ozone air purifier/drinking water ozonator
Specifications
| Model: Lonlf-OXF005 |
| Voltage: 220V |
| Power consumption: 450W |
| Ozone output: 5.0 grams per hour |
| Quartz Tube type discharge |
| Floor mounted |
| PSA oxygen generator built inside |
| Oilless air compressor built inside |
| Oxygen flow meter 3-5LPM |
| Individual team ON/OFF switch |
| Ozone concentration: 20-45mg/L |
| 0-100% ozone output regulating |
| Compressed air feed pressure |
| Free accessories: silicon hose 10 meters; 1 x venturi 3/4" |
Application
Ozone Concentrationsin water treatment
In water treatment, the solubility of ozone scope is 0.1mg / L ~ 10mg / L. The lower concentration could be for water disinfection and purification. And a high concentration could be as "ozone water disinfectant";
Tap water purification: International concentration level is 0.4PPM ( Mg/L), the treating time is 4 minute. The CT will be 1.6;
The dissolved ozone concentration 0.1-0.5Mg/L in water, to meet disinfection purposes within 5-10 minutes.
Ozone water disinfection and sterilization is rapid and occur in an instant. To kill the bacteria in 0.5-1.0 minute; Under the concentration of 4PPM (mg / L) to kill hepatitis B virus 100% in 1.0 minute.
Herbold reports: Under 20 °C conditions, the ozone concentration in water 0.43mg / L, can be 100% kill of E. coli, and under the 10 °C to kill all E. Coli at 0.36Mg/L only;
The ozone concentration 0.25-0.38Mg/L, kill all HAV in the several minute.
Mineral water: The solubility of ozone in the 0.4 ~ 0.5mg / L can meet the requirements of sterilization. The ozone dosage is 1.5 ~ 2.0mg /L.
Bottled water: Require the ozone dissolved in water 0.3-0.5mg/L; The ozone dosage is 2 grams per 1000 liters water. According to practical experience, the ozone gas concentrations higher than 8mg / L will be susceptible to meet this level.
Category |
Dual Water |
Pure water |
Natural water |
Tap water |
Swimming pool |
Ozone dissolved in water |
0.1-0.3mg/L |
0.2-0.4mg/L |
0.4-0.6mg/L |
0.4mg/L |
0.2mg/L |
Ozone dosage |
1-2g/1000L |
2-3g/1000L |
3-5g/1000L |
3-5g/1000L |
1-2g/1000L |
Product picture
Venturi 001 Long life Ozone Venturi injector
http://longlifeozone.en.china.cn/product/60238482910-219611364/Long_life_PVDF_material_Ozone_Venturi_injector_1_5_.html
Ozone Application Picture
CE Certificate
