Wash, Dewatering and Classifying Spiral Classifier for Sale
- 41 Set / Sets per Month
- Qingdao Tianjin
- T/T Credit Card
- Hot sale best price metal ore crusher,metal ore crusher with CE
- Hot Selling jaw stone crusher jaw grinder and crusher manufacturer
- Hot Selling jaw stone crusher jaw crusher capacity 110-250tons congo
- Hot sale New type sand making plant in india for sale with low price
- High quality crushed stone processing and pulverized mineral processing
- Zenith construction sand making plant,construction sand making plant price
Product Details
Condition: | New | Type: | Other, Sprial Separator, Mineral equipment, spiral classifier | Place of Origin: | Henan, China |
Brand Name: | Xingbang | Model Number: | FG | Warranty: | for the whole using life |
Product Description
Specifications
1. Efficient, ISO9001:2008 Quality Authentication2. reliable performance
3. High quality
4. Good Price
5. Long Using Life
Efficient Spiral Classifier
Spiral Classifier Introduction:
This screw washing machine is mainly used for sand factory, electric pole factory, work-site of building and concrete dam to wash, classifying and de-watering various sands. This sand washer adopt inclination of 15,under the water tub, three weir plates form the sediment pool, the screw head is immersed in this pool, the screw is driven by electric motor through reducer rotating continuously, the fresh water is feeding from porous plate at bottom of sediment pool, this machine have three functions of washing, de-watering, classifying.
Wash, Dewatering and Classifying Spiral Classifier for Sale
Type
| Spiral diameter (mm) | Flume length(mm) | Spiral speed (r/min) | Capacity (t/d) | Motor power(kw) | Weight (t)
| ||
Return sand | Overflow
| drive | upgrade |
| ||||
FG7.5 | 750 | 5500 | 6-10 | 340-70 | 65 | 3.0 | Manual
| 2.7 |
FG10 | 1000 | 6500 | 5.0-8.0 | 675-080 | 110 | 5.5 | Manual
| 4.43 |
FG12 | 1200 | 6500 | 5.0-8.0 | 1170-870 | 155 | 5.5 | 1.5 | 8.7 |
FG15 | 1500 | 8400 | 4.0-6.0 | 1830-2740 | 235 | 7.5 | 2.2 | 12.5 |
FG20 | 2000 | 8400 | 4.0-6.0 | 3240-5400 | 400 | 11 | 2.8 | 20.5 |
FG24 | 2400 | 9210 | 3.6 | 3240-5400 | 580 | 15 | 3.0 | 25.6 |
FG30 | 3000 | 1250 | 3.2 | 11625 | 890 | 22 | 4.0 | 37.7 |
2FG12 | 1200 | 6500 | 5.0-8.0 | 2340-3740 | 310 | 5.5×2 | 1.5×2 | 14.0 |
2FG15 | 1500 | 8400 | 4-6.0 | 3660-5480 | 470 | 7.5×2 | 1.5×2 | 21.1 |
2FG20 | 2000 | 8400 | 3.0-5.5 | 7780-11880 | 800 | 11×2 | 2.8×2 | 36.5 |
2FG24 | 2400 | 9210 | 3.6 | 13600 | 1160 | 15×2 | 3×2 | 46.8 |
2FG30 | 3000 | 12500 | 2.0-3.0 | 14600-23400 | 1785 | 22×2 | 4×2 | 73.0 |
FC12 | 1200 | 8400 | 5-8 | 1170-1870 | 120 | 7.5 | 2.2 | 10.4 |
FC15 | 1500 | 10500 | 4.0-6.0 | 1830-2740 | 185 | 7.5 | 2.2 | 16.8 |
FC20 | 2000 | 12900 | 2.0-5.5 | 3895-5940 | 320 | 15 | 2.8 | 29.1 |
FC24 | 2400 | 14200 | 2.5-4.0 | 4650-7450 | 455 | 18.5 | 4 | 41.0 |
FC30 | 3000 | 14200 | 3.2 | 11625 | 705 | 30 | 4 | 56.8 |
2FC15 | 1500 | 10500 | 4.0-6.0 | 2280-5480 | 370 | 7.5×2 | 1.5×2 | 30.7 |
2FC20 | 2000 | 12900 | 3.0-5.5 | 6480-11800 | 640 | 11×2 | 3×2 | 50.0 |
2FC24 | 2400 | 14200 | 3.67 | 9300-14900 | 910 | 18.5×2 | 4×2 | 67.9 |
2FC30 | 3000 | 14300 | 3.2 | 23300 | 1400 | 30×2 | 4×2 | 85.3 |
Thank you for taking time to go through our spiral classifier, if you have any question and inquiry and comments, pls feel free to contact us.
