China Hot Sell Sand Washing Machine For Cement/Quarry
- 48 Set / Sets per Month
- Qingdao Shanghai Xiamen Tianjin Based on your designation or destination
- T/T L/C D/P D/A Credit Card PayPal
- Mining Stone Crushing Machine Silica Quartz Sand Making Production Line
- High Efficiency Stone Fine Crusher 5X Series Sand Making Machine
- High Efficient Artificial Building VSI Crusher Sand Making Machine Equipment
- Automatic Zero Discharge Concrete Recycling System
- Concrete Batching Plant Parts
- Concrete Recycling Machine
Product Details
Condition: | New | Production Capacity: | 100t/h | Place of Origin: | Henan, China |
Brand Name: | XBM | Model Number: | XSD3016 | Voltage: | depend on yours |
Power(W): | 15kw | Dimension(L*W*H): | 3845*3000*3080 | Weight: | 8t |
Certification: | ISO, CE | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
sand washer:1. easy operation
2. high capacity
3. widely used
4. strong structure
China Hot Sell Sand Washing Machine For Cement/Quarry
1. Usage and Application of sand washer
Sand Washing Machine is a high-efficiency sand washing equipment adopting wheel-like structure, which works with sand making machine. It can wash the stone powder and impurity from the mixed sand that made by sand making machine, which can improve the sand quality. The Sand Washing Machine is widely used in washing, grading and dehydrating in the industry of stone factories, construction site and quartz sand in glass factory.
2.Features of sand washer
1. High efficiency, reasonable structure, high capacity and low consumption
2. The bearing device of impeller drive is separated from water and materials in water, which greatly protects the bearing from soaking, sand and pollutants.
3. Compared with the spiral sand washing machine, the loss of medium and fine sand and powder is minimized, and the grade and fineness can meet the required standard
4. This machine is with long service life and low maintenance costs
3. Operating principle of sand washer
The electric motor runs slowly with the impellor after decelerated by the belt, decelerator and gears wheel. The sand and stone flow into washing launder from feeding launder, rolls with the impellor, and grinds each other. The impurity covering the sand is washing away. At the same time, add more water, the strong water flow will take away waste and some low-weight wastes from washing launder. Through the above process, the washing function is finished. The clean sand and stone is lift up by vane. When it goes up slowly, the water begins to drop through the mesh and fall back in the washing launder. On one hand, water is removed from the sand and stone; on the other hand, the water can be fully used. Finally, the sand and stone goes to the out launder from the rotary impellor to finish the washing task.
4. Specification of sand washer
Model | Wheel Size (mm) | Max feed size (mm) | Power (kW) | Weight (t) | Capacity (t/h) | Overall dimension (mm) |
XSD2610 | Φ2600×1000 | 10 | 5.5 | 2.7 | 20-50 | 3255×1982×2690 |
XSD2816 | Φ2800×1600 | 10 | 11 | 3 | 30-60 | 3540×3000×2880 |
XSD3016 | Φ3000×1600 | 10 | 15 | 3.3 | 50-100 | 3845×3000×3080 |
Thanks for your support. Trust is the first step of business. We are waitting for your visit during our working time. Please contact us if you have any problems.(We supply all types of mining machines as your order)
