Temperature Control System Furnace of Limestone/ Cement Aluminium Active Carbon Rotary Kiln for Melting |
Henan XBM specialize in manufacture Rotary Kiln, 20 years experiences, professional design, first-class quality, sales lead !
Introduction of XBM Rotary Kiln: |
Rotary kiln belongs to building material equipment, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials.
Cement kiln is used for making of cement clinker and there are dry and wet methods to make cement. metallurgy chemical kiln is used in metallurgy industry and ironworks for lean iron ore, chromium ore and ferronickel ore calcimine. Rotary kiln is used for calcimine of high aluminum vandal ochre in refractory material industry; for calcimine of calotte and aluminum hydroxide in aluminum manufacturer; for claiming of chrome sand ore and chrome powder ore in chemical plant.
Working Principle of XBM Rotary Kiln: |
- With a certain slope to the level, the whole lime rotary kiln body is supported by rollers and fitted with thrust rollers to control up and down movement of the kiln body.
- Besides main driving unit for driving system, it is also fitted with the auxiliary driving unit so as to ensure the kiln body still can rotating when the main motor is powered off and prevent it from deforming.
- The lime rotary kiln head adopts housing type sealing and kiln rear uses axial contact sealing unit so that reliability of sealing could be ensured.
Classification of XBM Rotary Kiln: |
- Cement kiln;
- Metallurgy chemical kiln;
- Active lime kiln;
- Porcelain kiln according;
- Building material kiln;
- Calcined petroleum coke rotary kiln.
XBM rotary kiln has strong structure, stable operation, high-quality products from the kiln and so on advantages, we can also offer advanced efficient shaft pre-heater, five grade cyclone preheater.
Structures of XBM Rotary Kiln: |
Rotary kiln is mainly composed of cylinder, under frame, feeding and discharging devices, transmission device, gears etc. (Optional auxiliary equipment includes combustion chamber, feeder and discharging device, and dust collection equipment). Rotary drier manufactured by us adopts new lifting plate, which is of functions like guiding, current-sharing, and material raising. The materials are raised and evenly drop so that they are in full contact with heat for better drying efficiency. Our rotary drier is designed with the best working conditions, which enables it to save 10-15% of energy and increase 10-15% of productivity compared with common dryers.
Parameters of XBM Rotary Kiln: |
Model | Kiln Dimensions | Capacity (t/d) | Rotation speed (r/min) | Motor Power(kw) | Total Weight(t) | Note | ||
Diameter (m) | Length (m) | Obliquity (%) | ||||||
| 2.5×40 | 2.5 | 40 | 3.5 | 180 | 0.44-2.44 | 55 | 149.61 | Kiln with shaft cyclone preheater |
| 2.5×50 | 2.5 | 50 | 3 | 200 | 0.62-1.86 | 55 | 187.37 | ---- |
| 2.5×54 | 2.5 | 54 | 3.5 | 204 | 0.48-1.45 | 55 | 196.29 | ---- |
| 2.7×42 | 2.7 | 42 | 3.5 | 320 | 0.10-1.52 | 55 | 198.5 | ---- |
| 2.8×44 | 2.8 | 44 | 3.5 | 400 | 0.437-2.18 | 55 | 201.58 | Outside disassemble kiln |
| 3.0×45 | 3 | 45 | 3.5 | 500 | 0.5-2.47 | 75 | 210.94 | ---- |
| 3.0×48 | 3 | 48 | 3.5 | 700 | 0.6-3.48 | 100 | 237 | Outside disassemble kiln |
| 3.0×60 | 3 | 60 | 3.5 | 300 | 0.3-2 | 100 | 310 | Alumyte-alumina forge kiln |
| 3.2×50 | 3.2 | 50 | 4 | 1000 | 0.6-3 | 125 | 278 | Outside disassemble kiln |
| 3.3×52 | 3.3 | 52 | 3.5 | 1300 | 0.266-2.66 | 125 | 283 | Kiln with preheater precalcine |
| 3.5×54 | 3.5 | 54 | 3.5 | 1500 | 0.55-3.4 | 220 | 363 | Kiln with preheater precalcine |
| 3.6×70 | 3.6 | 70 | 3.5 | 1800 | 0.25-1.25 | 125 | 419 | Generating kiln for using ofterheat |
| 4.0×56 | 4 | 56 | 4 | 2300 | 0.41-4.07 | 315 | 456 | Kiln with preheater precalcine |
| 4.0×60 | 4 | 60 | 3.5 | 2500 | 0.396-3.96 | 315 | 510 | Kiln with preheater precalcine |
| 4.2×60 | 4.2 | 60 | 4 | 2750 | 0.4-3.98 | 375 | 633 | Kiln with preheater precalcine |
| 4.3×60 | 4.3 | 60 | 3.5 | 3200 | 0.396-3.96 | 375 | 583 | Kiln with preheater precalcine |
| 4.5×66 | 4.5 | 66 | 3.5 | 4000 | 0.41-4.1 | 560 | 710.4 | Kiln with preheater precalcine |
| 4.7×74 | 4.7 | 74 | 4 | 4500 | 0.35-4 | 630 | 849 | Kiln with preheater precalcine |
| 4.8×74 | 4.8 | 74 | 4 | 5000 | 0.396-3.96 | 630 | 899 | Kiln with preheater precalcine |
| 5.0×74 | 5 | 74 | 4 | 6000 | 0.35-4 | 710 | 944 | Kiln with preheater precalcine |
| 5.6×87 | 5.6 | 87 | 4 | 8000 | Max4.23 | 800 | 1265 | Kiln with preheater precalcine |
| 6.0×95 | 6 | 95 | 4 | 10000 | Max5 | 950×2 | 1659 | Kiln with preheater precalcine |
Application of XBM Rotary Kiln: |
1) Rotary kiln is the Thermal Equipment, heating materials, in cement industry for calcining clinker.
2) It is also used in various industries, such as cement, nonferrous metallurgy, ferrous metallurgy, chemistry, building, refractory material, environmental protection, etc.
Advantages of XBM Rotary Kiln: |
- Through technological innovation, our rotary kiln is designed with international leading wheel catch device, high precision plunger metering pump, high accuracy speed control valve and contact graphite block sealing device, etc.
- In order to improve machinery automation, an industrial computer is used for showing the calcining condition, and a fluorescent screen is adopted for showing the simulated process flows. An infrared scanner is utilized for transmitting the calcining condition to the computer.
- These new technologies provide our rotary kiln with strong visual sense, convenient operation and reliable performance. They help stabilize thermal regulation and improve operation efficiency.
- Comparing with other similar cement production equipment, the operation rate of our rotary kiln increased by 10%, production increased by 5%-10% and heat consumption decreased by 15%.
Our packing and payment terms:
1. We usually accept T/T, L/C,
2. T/T: 30% in advance as down payment, the balance before delivery;
3. We take pictures of finished products before delivery.
Ways of packing:
1.Sand blasting, coat with high quality paint;
2.Product wrap by PP-Bubble
3.Load container, Spear Parts in wooden case.
Transportation:
1. By sea freight:APL,COSCO, OOCL,MSK CSCL, MSC, etc.
2. We will remind you before boat arrival.
Personalized reception: Offer the full and personalized service in the whole journey after you come to China.
Lifetime Technical Support: Offer one year of free equipment warranty and lifetime technical support.
Monitor Production Progress: You can monitor production progress personally any time after confirming the order.
Product Delivery: We have developed a long and good relationship with many shipping agents, such as APL, MSK, CSCL, MSC, etc.
Installation and Training: Send technicians to the client site for guiding the installation and adjustment, and training operators to complete the inspection and acceptance together with you.
Henan Xingbang Heavy Machinery Co., Ltd.(XBM) is a largescale enterprise with Integration of researching, development, manufacturing and marketing mining machinery. Our main business scope is: stone crushing series, industrial grinding series, ore dressing equipment and cement equipment.
Our products have been exported to a number of foreign countries, including southeastern Asia, South Africa, South America etc. And numerous customers have come to visit our factories with the purpose of choosing their ideal machine. China XBM always bears in mind the aim "Quality First; Honesty Foremost"!
Over 20 years experiences in this field; Exported to more than 30 countries in Africa, Asia, America; Processional Research and Development team; Strict quality control; Provide complete service equipment installation, testing ,maintenance and staff training.....
All XBM people sincerely welcome talents and customers all over the world to come and visit our factory!
Looking forward to cooperating with you ! Tel:86-13683809990
Best Service Biggest sincerity Trustworthy
