AAC block making plant cutting machine
- 20 Set / Sets per Month
- Qingdao Shanghai Xiamen Tianjin Based on your designation or destination
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Interlock Block Making Machine | Brick Raw Material: | Concrete |
Processing: | Brick Production Line | Method: | Autoclaved Aerated Concrete | Automatic: | Yes |
Capacity: | 50000m3/year | Place of Origin: | Henan, China | Brand Name: | XBM |
Model Number: | 50,000m³/year | Voltage: | 380V | Power: | 280KW |
Dimension(L*W*H): | 45*20*20m | Certification: | ISO9001/CE | Warranty: | 12months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
duction rate over 98%.2.High automatic,low manpower
3.exported to many countries
4.ISO9001:2008
1. Basic Introduction of aac block plant /aac autoclave block machine/ aac block production line
Autoclaved Aerated Concrete (AAC) is a siliceous material (sand, fly ash and silicon tailings such as waste porcelain clay, stone processing waste materials, blast furnace slag, etc.) and calcareous materials (lime, cement) as the main raw material, mixing fat gas agent (aluminum powder), by ingredients, mixing, casting, preraising, cutting, autoclave, curing process made of light porous silicate products, because by the hair contains a lot of gas even after the small pores, hence the name of aerated concrete.
aerated autoclaved concrete plant, AAC block, aac production line, aac plant, AAC brick, autoclave aerated concrete block, concrete block machine, light weight block
2. Advantages of aac block plant /aac autoclave block machine / aac block prodution line 2.1, Lightweight:The aerated concrete dry bulk density generally is 400-800kg/m3, equivalently to clay brick 1/3, normal concrete 1/5, lower than normal light-weight aggregate concrete and hollow
brick, hollow clay brick. so, using aerated concrete as wall material can lighten the building self weight, and then reduce the size of building foundation, girder and pillar etc. Structure, save building material and project cost, improve the building shock resistance.
Several common building material volume density (kg/m3)
material | aerated concrete | wood | clay brick | lime and sand brick | hollow brick | ceramsite concrete | normal concrete |
index | 400-800 | 400-650 | 1600-1800 | 1700-1800 | 900-1700 | 1400-1800 | 2000-2400 |
2.2, Fireproof: Most of the major raw materials is inorganic materials, so it has good fire resistance, and do not emit harmful gases when meet fire. Fire 650 degrees, as a refractory material, the thick up of 90mm walls can reach to 245 minutes fire resistance, 300mm thick up wall can reach to 520 minutes fire resistance.
2. 3,Sound insulation: Due to a unique porous structure, so it has a sound absorption capacity. The sound absorption capacity can reach of 10mm thick wall up to 41 db.
2.4, Insulation: As the material inside has a large numbers of the pores and porous, which has a good thermal insulation properties. The Thermal conductivity is 0.11-0.16W/MK, as 1/4-1/5 of brick. Typically, the insulation effect of 20cm thick aerated concrete wall is equivalent to 49cm thick solid brick walls ordinary.
2.5, Permeability: Result of material by the composition of many independent small pores, the moisture absorption is slow, in the volume of absorbent is 5 times of clay saturation do. When used in the bathroom, the wall can be treated to interface directly paste tiles.
2.6, Anti-seismic:The same building structure, improve the two seismic than the brick level.
2.7, Green: Manufacturing, transportation, all use the process of pollution, to protect arable land, saving energy, is one kind of a green building material.
2.8, Durability: material strength is stability, in the specimens tested after one year of atmospheric exposure; the intensity increased by 25%, and remained stable after ten years.
2.9, Shortcut: it has good machinability, can be sawed, planed, drilled, nailed, and available appropriate as bonding of adhesive material, so create favorable conditions for building construction.
2.10, Economies: An integrated lower cost than using more than 5% of solid clay bricks, and can increase the usable area, greatly enhance the utilization of floor space.
3. Performance of aac block plant/aac block production line/ aac concrete block production line
Finished AAC block is Suitable for all nonbearing wall and bearing wall of multi-story (less than six-floor), nonbearing wall internal parting wall, thermal insulation rooms front panel, floorslab.
3.1, Unit weight grade (kg/m3): 500, 600, 700, 800 (means 05,06,07,08 grade)
3.2, Compression strength grade (Mpa): A3.5, A5.0, A7.5, A10.0 (1Mpa=10kg/m2)
3.3, Drying shrinkage (mm/m): ≤ 0.8
3.4, Heat conductivity(w/m.k): 0.09-0.22
3.5,Sound-proofing performance(db): 40-47.75
Conforming with China national standards GB11968-1997 (the latest AAC block national standard)
4. Normal size of aac block plant /aac autoclave block machine/ aac concrete block production line
Length (mm): 600
Width (mm): 75, 100, 125, 150, 175, 200, 250
60, 120, 180, 240
Height (mm): 200, 240, 250, 300
Remarks: the size can be customized
5. Main Raw maerial of autoclaved aerated concrete block/aac block plant /aac concrete block production line
5.1 Typical Formula and Consumption of Fly ash AAC /aac block plant
Fly ash: content ratio 70%, consumption 350kg/m3; Cement: content ratio 13.8%, consumption 25-30kg/m3; Lime: content ratio 13.8%, consumption 140-150kg/m3; Phosphogypsum: content ratio 2.96%, consumption 15kg/m3; Aluminum: micro scale, consumption 0.4kg/m3
5.2 Typical Formula and Consumption of Sand AAC /aac block plant
Sand: content ratio 69.2%, consumption 350kg/m3; Cement: content ratio 13.8%, consumption 70kg/m3; Lime: content ratio 13.8%, consumption 70kg/m3; Gypsum: content ratio 2.96%, consumption 15kg/m3; Aluminum: micro scale, consumption 0.4kg/m3
7. Main equipments in aac bock plant / aac oncrete block production line
7.1, Material-milling Equipments:
a. Crusher: Lime, gypsum, and such kind of bulk material need to be crushed as the first step in AAC Plant.
b. Ball mill: The AAC material must be fully grinded in order to make better reaction. Ball Mill is used widely, it has two types: dry and wet, can be chosen upon requirement.
7.2, Material Metering Equipments: Computer Control Automatic Metering System is commonly used as measurement of raw materials.
7.3, Material mixing and casting equipments: Mixer, it’s the slurry mixing machine, also is slurry casting machine.
7.4, Cutting Machine: the AAC blank is formed after casting and precuring, as the size is too large, it must be cut to achieve the required product size.
7.5, Autoclave: Autoclave is a device for silicate hydration products to get physical and mechanical properties.
7. 6, Boiler: the boiler supports for the autoclave and preheat furnace and other facilities with heat.
