Home > Products > Spreader roll & Bow roll & Banana roll > high quality sludge dewatering machine
high quality sludge dewatering machine
- 2 Set / Sets per Month
- qingdao
Product Details
Condition: | New | Type: | Pulping Equipment | Computerized: | Yes |
Place of Origin: | Shandong, China | Brand Name: | daxing | Model Number: | 500-4000 |
Voltage: | 380 | Weight: | 5-9T | Certification: | ISO9001:2000 |
Warranty: | 6 MONTH | After-sales Service Provided: | Overseas third-party support available |
Packaging Details
wooden case
Product Description
Belt type filter press for sludge dewatering machine
Overview
Introduced the advanced technology from American, RBYL-Belt filter press is a sewage treatment device which can continuously press large amounts of sludge. By using high strength material, the device is characterized in large treating capacity, high dewatering efficiency and long service life. The high quality belt and long life bearing ensure the device’s performance and quality and make it widely used in the sewage treating industries.
Advantage
(1) Automatic control and continuous working
(2) Low energy cost and long service life
(3) High dewatering efficiency and high solid containing rate of mud cake
(4) Easy maintenance and management
(5) Low noise and less chemicals
(6) Economical and reliable, wide application.
Structure
The device is equipped with two belts. There is a long gravity dehydration area which can improve the dehydration effect and lower the cost by reducing the usage of chemicals.
Technical Parameter Table
Item | Model | |||||||||||||||||||
RBYL-500 | RBYL-700 | RBYL-1000 | RBYL-1500 | RBYL-2000 | RBYL-2500 | RBYL-3000 | RBYL-4000 | |||||||||||||
Main engine | Power (kw) | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 3 | 4 | 4 | |||||||||||
Air compressor | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | ||||||||||||
Belt width (mm) | 500 | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 4000 | ||||||||||||
Capacity (m3/h) | 3~4 | 4~6 | 5~7 | 8~10 | 12~15 | 15~18 | 18~25 | 25~30 | ||||||||||||
Overall dimension | Length(mm) | 4920 | 4920 | 4920 | 4920 | 4920 | 4920 | 4920 | 4920 | |||||||||||
Width(mm) | 978 | 1178 | 1478 | 1978 | 2478 | 2978 | 3478 | 4678 | ||||||||||||
Height(mm) | 2350 | 2350 | 2350 | 2350 | 2350 | 2350 | 2350 | 23500 | ||||||||||||
Feeding concentration | 0.2-8% | |||||||||||||||||||
Discharge concentration |
Company Profile
Shandong Zhangqiu Daxing Paper-making Machinery Co., Ltd. Has a research and development, production and processing, sales management, technical services as one of the paper machine roller of professional manufacturers.
Our company has years' production experience and strong technical force including 66 engineers and 316 employees, and its fixed assets have amounted to 26 million yuan. It has 58 sets of professional production and testing equipment and four sets of large processing equipment with the working range of dia2000*10000. We boast fine equipment, sound quality guarantee system, complete detection means and technological equipment. Through the ISO9001 international quality system certification.Our products include papermaking glue roll (press roll, touch roll, sizing roll), copper roll (chest roll), chrome-plated roll, glass steel roll, steel roll, textile roll, printing roll, and dyeing roll. Our products are sold to all over the world, such as the USA, Germany, Japan, Russia, Indonesia, India, Bangladesh, and Pakistan.
Since its inception, the spirit of "quality first, customer the best return," the purpose, we produced the "daxing" brand products to the best quality, lowest price, best service to win the majority of users ages.
