Specifications
sludge dewatering machine1. International Advanced Technology
2.Large capacity
3.full automatic
Belt type filter press for sludge dewatering machine
Overview
Introduced the advanced technology from American, RBYL-Belt filter press is a sewage treatment device which can continuously press large amounts of sludge. By using high strength material, the device is characterized in large treating capacity, high dewatering efficiency and long service life. The high quality belt and long life bearing ensure the device’s performance and quality and make it widely used in the sewage treating industries.
Advantage
(1) Automatic control and continuous working
(2) Low energy cost and long service life
(3) High dewatering efficiency and high solid containing rate of mud cake
(4) Easy maintenance and management
(5) Low noise and less chemicals
(6) Economical and reliable, wide application.
Structure
The device is equipped with two belts. There is a long gravity dehydration area which can improve the dehydration effect and lower the cost by reducing the usage of chemicals.
Technical Parameter Table
Item | Model | |||||||||||||||||||
RBYL-500 | RBYL-700 | RBYL-1000 | RBYL-1500 | RBYL-2000 | RBYL-2500 | RBYL-3000 | RBYL-4000 | |||||||||||||
Main engine | Power (kw) | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 | 3 | 4 | 4 | |||||||||||
Air compressor | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | ||||||||||||
Belt width (mm) | 500 | 700 | 1000 | 1500 | 2000 | 2500 | 3000 | 4000 | ||||||||||||
Capacity (m3/h) | 3~4 | 4~6 | 5~7 | 8~10 | 12~15 | 15~18 | 18~25 | 25~30 | ||||||||||||
Overall dimension | Length(mm) | 4920 | 4920 | 4920 | 4920 | 4920 | 4920 | 4920 | 4920 | |||||||||||
Width(mm) | 978 | 1178 | 1478 | 1978 | 2478 | 2978 | 3478 | 4678 | ||||||||||||
Height(mm) | 2350 | 2350 | 2350 | 2350 | 2350 | 2350 | 2350 | 23500 | ||||||||||||
Feeding concentration | 0.2-8% | |||||||||||||||||||
Discharge concentration | ||||||||||||||||||||
