Low Price Sinker Edm D7160

Low Price Sinker Edm D7160 thumbnail-1
Low Price Sinker Edm D7160 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
JZ
Model Number:
D7160
Contact Supplier Request Quote Chat Now
Taizhou Jiangzhou Numerical Control Machine Tool Manufacture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name JZ
Model Number D7160
Condition New

Specifications

CNC Die Sinking EDM Machine D7160
Sanyo DC servo motor
most advanced motherboard
high accuracy
TM/ ISO9001:2008



low price sinker edm D7160

CNC Die Sinking EDM Machine D7160

Machine type Unit D7160
Worktable size(L×W) mm 1000×600
Work tank dimension(L×W×H) mm 1680×850×580
X axis travel mm 600
Y axis travel mm 450
Z axis travel mm 250+350
Distance between electrode&worktable mm 800
piece weight kg 1000
Max.electrode weight kg 150
Machine weight kg 3000
Machine dimension(L×W×H) mm 1700×1600×2400



low price sinker edm D7160low price sinker edm D7160

This machine matches with the pulse source cabinet.

Z axis matches Japanese Sanyo DC servo motor and it has Z axis CNC features.

X,Y axes adopt precise ball screw and raster display to conduct coordinate display, which make high precision positioning.

The electric box uses the most advanced industrial special mainboard.

As long as you input a few parameters like Z-axis depth, it will bring up suitable data from the rich expert database system, automatically achieving roughing to finishing.

   low price sinker edm D7160
