AAC Cable,Aluminium AAC Cable,overhead Aac Cable
Insulation Material : XLPE , Polyethylene(PE)
Conductor Material: Aluminum
Model No : Single , Duplx , Triplex Quadruplex
Bare Conductor
| Item No |
Cross Section(mm2) |
Conductor Diameter(mm) |
Overall Diameter(mm) |
| DL-1 | 10 | 7X1.35 | |
| DL-2 | 16 | 7X1.70 | 5.1 |
| DL-3 | 25 | 7X2.14 | 6.4 |
| DL-4 | 35 | 7X2.52 | 7.5 |
| DL-5 | 50 | 19X1.83 | 9.0 |
| DL-6 | 70 | 19X2.17 | 10.8 |
| DL-7 | 95 | 19X2.50 | 12.4 |
| DL-8 | 100 | 19X2.59 | 13.0 |
| DL-9 | 120 | 19X2.80 | 14.2 |
| DL-10 | 150 | 37X2.25 | 15.7 |
| DL-11 | 185 | 37X2.50 | 17.5 |
| DL-12 | 210 | 19X3.75 | 18.7 |
| DL-13 | 240 | 61X2.25 | 20 |
| DL-14 | 300 | 61X2.50 | 22.4 |
| DL-15 | 400 | 61X2.89 | 26 |
| DL-16 | 500 | 61X3.23 | 29 |
PVC / PE Insulation
| Item No |
Cross Section(mm2) |
Conductor Diameter(mm) |
Overall Diameter(mm) |
| DL- 17 | 1x10+1x10bare | 7x1.35 | 1.2 |
| DL- 18 | 1x16+1x16bare | 7x1.70 | 1.2 |
| DL- 19 | 1x25+1x25bare | 7x2.14 | 1.2 |
| DL- 20 | 1x35+1x35bare | 7x2.52 | 1.4 |
| DL- 21 | 1x50+1x50bare | 19x1.78 | 1.4 |
| DL- 22 | 1x70+1x70bare | 19x2.14 | 1.4 |
| DL- 23 | 2x16+1x16bare | 2x7x1.70 | 1.2 |
| DL- 24 | 2x25+1x25bare | 2x7x2.14 | 1.2 |
| DL- 25 | 2x35+1x35bare | 2x7x2.52 | 1.4 |
| DL- 26 | 2x50+1x50bare | 2x19x1.78 | 1.4 |
| DL- 27 | 2x70+1x70bare | 2x19x2.14 | 1.4 |
| DL- 28 | 3x16+1x16bare | 3x7x1.70 | 1.2 |
| DL- 29 | 3x25+1x25bare | 3x7x2.14 | 1.2 |
| DL- 30 | 3x35+1x35bare | 3x7x2.52 | 1.4 |
| DL- 31 | 3x50+1x50bare | 3x19x1.78 | 1.4 |
| DL- 32 | 3x70+1x70bare | 3x19x2.14 | 1.4 |
The ABC cable (Aerial Bundled Cable) are used for power tranmisson , specially for rebuiding of urban and forest regions . Which can improves safety and reliance of electrified wire netting.
