China Effective Gypsum Mobile Cone Crusher Price
China Effective Gypsum Mobile Cone Crusher Price
Overview of Cone Crusher
Name |
Cone Crusher |
Type |
Secondary Crushing |
Input Size |
40-300 MM |
Processed Materials |
Cobble, Basalt, Iron ore, copper ore, gold ore, manganese ore, gravel, granite, basalt, mine ore, quartz, diabase, etc. (for hard stone) |
Applications |
Aggregate field, concrete mixing plant, dry mortar plant desulfurization, quartz sand, etc. |
- Cone Crusher breaks material by squeezing or compressing it between convex and concave shaped surfaces covered by manganese as the wear surface.
- Normally used as the secondary or tertiary crusher, the cone crusher has been developed to crush high or medium hardness material, such as iron ore ,copper ore, limestone, quartz, granite, and sand stones, etc.
- Cone Crusher has been developed to crush feed materials into desired end products efficiently, reliably and economically.
- This series offers the highest crushing efficiency and end product quality with the lowest cost per tone production.
- The safety system uses dry oil and water as two kinds of sealed formation to make plaster powder and engine oil separate to make sure reliable performance.
- The type of crushing chamber depends upon size of feeding and fineness of crushed product.
- The standard type (PYB) is applied to medium crushing, the medium type is applied to medium or fine crushing and the short head type is applied to fine crushing.

Specifications of Used Cone Crusher
Type |
Max. input (mm) |
Adjusting range of output (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (t) |
Overall dimensions (L×W×H)(mm) |
|
PYB |
600 |
65 |
12-25 |
12-25 |
30 |
5 |
2800×1300×1700 |
PYD |
35 |
3-15 |
5-23 |
5.5 |
|||
PYB |
900 |
115 |
15-50 |
50-90 |
55 |
10.2 |
3050×1640×2350 |
PYZ |
60 |
5-20 |
20-65 |
10.2 |
|||
PYD |
40 |
3-13 |
15-50 |
10.3 |
|||
PYB |
1200 |
145 |
20-50 |
110-200 |
110 |
24.7 |
4152×2300×2980 |
PYZ |
100 |
8-26 |
50-150 |
25 |
|||
PYD |
50 |
3-15 |
18-105 |
25.6 |
|||
PYB |
1750 |
215 |
25-60 |
280-480 |
160 |
50.3 |
4870×3800×4192 |
PYZ |
185 |
10-30 |
115-320 |
50.3 |
|||
PYD |
85 |
5-15 |
75-230 |
50.4 |
|||
PYB |
2200 |
300 |
30-60 |
590-1000 |
260-280 |
80 |
7705×3430×4852 |
PYZ |
230 |
10-30 |
200-580 |
80 |
|||
PYD |
100 |
5-15 |
120-340 |
81.4 |
|||
.
