Specifications
Control cables PVC insulation
1, Widely Used in power transmission
2, Best quality, Low price
3, MOQ: 1km
4,free sample
Product Characteristic:
1 The rated voltage is 450/750v and under 450/750v. The pvc can be used in the place of 0.6/1KV.
1. the long-term working temperature: PVC and PE insulated should not be above 70°C, pvc insulated should not be
above 90°C.
2. The laying temperature should not be above -20°C.
3. The bending radius of cable: non armoured cable, should not be less than 6 times. Armoured or copper tape screen
should not be less than 12 times. The soft screen cable should not be less than 6 times.
Type |
Name |
Section Area(mm2) |
No. of Core |
Application Site |
KVV |
Copper Conductor,PVC Insulated and Sheathed Control Cable |
0.75 1.0 1.5 2.5 |
2-16 |
Permanent installation indoors,in cable ditches or pipes |
4 6 |
2-14 |
|||
10 |
2-10 |
|||
KVVP |
Copper Conductor,PVC Insulated and Sheathed,Braiding Shielded Control Cable |
0.75 1.0 1.5 2.5 |
2-61 |
Permanent installation indoors,in cable ditches or pipes where shielding is required |
4 6 |
2-14 |
|||
10 |
2-10 |
|||
KVVP2 |
Copper Conductor,PVC Insulated and Sheathed,Copper-tape Screened Control Cable |
0.75 1.0 1.5 2.5 |
4-10 |
Permanent installation indoors,in cable ditches or pipes where shielding is required |
4 6 |
7-61 |
|||
10 |
4-10 |
|||
KVV22 |
Copper Conductor,PVC Insulated and Sheathed,Steel tape Armored Control Cable |
0.75 1.0 1.5 2.5 |
7-61 |
Permanent installation indoors,in cable ditches,Be able to withstand stronger external mechanical force |
Company Information
Shenyi Wire & Cable Co.,Ltd(The former shenyang XLPE cable factory which founded in october 1993),located in tianbao west street north Industry clusters xicheng area ningjin county,hebei Province which called cable hometown.It covers an area of more than 50000 square meters,fixed assets of RMB 88 million,the registered capital of RMB10088 million,with more than 180 employees.
Production Line
As one of top rank cables manufacturers in China, our factory is mainly specialized in PVC Insulated Building Wire, PVC and XLPE Insulated Power Cable with Voltage up to 35kV, Rubber Cable and Welding Cables. And we also specialize in Aerial Bundled Cable(ABC Cable), Bare Overhead Power Transmission Line such as triplex overhead service conductors(AAC Conductor), All Aluminum Alloy Conductor(AAAC Conductor), Aluminum Conductor Steel Reinforced(ACSR Conductor), Aluminum Conductor Aluminum Clad Steel Reinforced (ACSR/AW), All Aluminum Alloy Steel Reinforced(AACSR), and Aluminum Conductor Aluminum Alloy Reinforced(ACAR).
Our People
Our company have high qualified workers. We have strong team sprit and responsibility. We are family!!!
